Phoenix Contact FKCOR254ST508LR PCB connector
The FKCOR 2.5/4-ST-5.08-LR is a four-pole female printed circuit board connector with a 5.08mm pitch, designed for industrial applications. It features an automatic locking mechanism and an intuitive color-coded release lever for easy operation. The connector enables quick and tool-free push-in spring connections with tin-plated contacts, supporting conductor cross-sections from 0.2mm² to 2.5mm² (24-12 AWG). Suitable for DIN-rail mounting, it supports rated voltages up to 630V, surge voltage of 4kV, and rated current of 12A, ideal for efficient wiring in industrial environments.
Phoenix Contact FKCOR254ST508LR PCB connector Specifications:
- Number of positions: 4
- Pitch: 5.08 mm
- Rated voltage: 320V (III/2) and up to 630V (Il/2)
- Rated surge voltage: 4kV
- Rated current: 12A
- Connection method: Push-in spring connection
- Conductor cross section: 0.2 mm² to 2.5 mm² (AWG 24-12)
- Insulating material: Not specified, designed for industrial PCB use
- Dimensions: Length 29.1 mm, Width 29.32 mm, Height 14.7 mm
- Stripping length: 10 mm
- Color: Green
- Contact surface: Tin-plated
- Flammability rating: UL 94 V-0
- Standards: EN-VDE compliant
- Mounting: DIN-rail
- Environmental: No hazardous substances above threshold, unlimited EFUP
Buy the Phoenix Contact Series FKCOR 2.5/4-ST-5.08-LR: FKCOR254ST508LR
Purchase the Phoenix Contact FKCOR 2.5/4-ST-5.08-LR connector online today to benefit from its quick push-in connection, robust tin contacts, and reliable performance. Designed for industrial PCB wiring, this four-pole connector offers a 5.08mm pitch, rated voltages up to 630V, and a rated current of 12A. Its DIN-rail mounting feature facilitates easy installation, while the automatic locking and color-coded release lever simplify wiring and maintenance. Secure your industrial applications with a dependable connector that combines efficiency and safety.
Order your Phoenix Contact Series FKCOR 2.5/4-ST-5.08-LR connector today and ensure quick, reliable wiring for industrial PCB applications.
Frequently Asked Questions
Where can I buy Phoenix Contact FKCOR254ST508LR?
You can click on the BUY or RFQ button to purchase FKCOR254ST508LR from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FKCOR254ST508LR?
You can download the FKCOR254ST508LR datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FKCOR254ST508LR?
Phoenix Contact
