Phoenix Contact FKCOR258ST508LR PCB connector
The Phoenix Contact FKCOR 2.5/8-ST-5.08-LR is a highly reliable PCB connector with an 8-pole female design, featuring a 5.08 mm pitch and tool-free push-in spring connection. It offers quick, secure wiring, thanks to spring-loaded contacts and an intuitive, color-coded release lever. Rated for 12A and voltages up to 630 V, it supports conductor cross sections from 0.2 mm² to 2.5 mm² (24-12 AWG). The connector's orthogonal wire orientation simplifies cabling in DIN rail devices, making it ideal for industrial automation and control systems. Its compact dimensions ensure ease of integration in space-constrained environments.
Phoenix Contact FKCOR258ST508LR PCB connector Specifications:
- Dimensions: Length 29.1 mm, Width 49.64 mm, Height 14.7 mm
- Pitch: 5.08 mm
- Rated current: 12 A
- Rated voltage: up to 630 V
- Number of positions: 8
- Connection method: Push-in spring connection
- Conductor cross section: 0.2 mm² to 2.5 mm² (AWG 24 to 12)
- Flammability rating: UL 94 V-0
- Stripping length: 10 mm
- Connection: Orthogonal wire orientation for simplified cabling
- Rated surge voltage: 4 kV
- Material: Tin-plated contacts
Buy the Phoenix Contact FKCOR 2.5/8-ST-5.08-LR – Reliable PCB Connector for Industrial Applications
Order the Phoenix Contact FKCOR 2.5/8-ST-5.08-LR online now and experience high-quality, secure, and quick connections for your industrial control and automation projects. With its push-in spring connection, orthogonal wire orientation, and rated for up to 12A and 630 V, this connector simplifies wiring and enhances system reliability. Its compact design and easy release lever make maintenance straightforward. Perfect for DIN rail-mounted devices, this connector optimizes space and ensures durable, maintenance-friendly connections for demanding industrial environments.
Get Phoenix Contact FKCOR 2.5/8-ST-5.08-LR today—built for reliable, tool-free wiring in industrial automation and control systems.
Frequently Asked Questions
Where can I buy Phoenix Contact FKCOR258ST508LR?
You can click on the BUY or RFQ button to purchase FKCOR258ST508LR from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FKCOR258ST508LR?
You can download the FKCOR258ST508LR datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FKCOR258ST508LR?
Phoenix Contact
