Phoenix Contact FKCOR258STF508 8-Pole Printed Circuit Board Connector
The FKCOR 2,5/8-STF-5,08 from Phoenix Contact is a 5.08 mm pitch, 8-pole female printed circuit board connector featuring a screw flange for enhanced mechanical stability. Its conductor connection is orthogonal to the device's operational direction, facilitating easy cabling for DIN-rail-mounted applications. The connector supports quick and convenient testing via an integrated test option and can be combined with the MSTB 2,5 range connectors. It features a tool-free push-in connection with color-coded actuation levers for intuitive use, tin-plated spring connection, and a rated surge voltage of 4 kV. The rated voltage options are 250V (III/3), 320V (III/2), and 630V (II/2), with a nominal current of 12A and a rated cross-section of 2.5 mm². The connector accepts solid conductors from 0.2 mm² to 2.5 mm² (AWG 24 to 12) and requires a stripping length of 10 mm. It is suitable for industrial applications.
Phoenix Contact FKCOR258STF508 8-Pole Printed Circuit Board Connector Specifications:
- Number of positions: 8
- Pitch: 5.08 mm
- Rated voltage: 250V (III/3), 320V (III/2), 630V (II/2)
- Rated surge voltage: 4 kV
- Rated current: 12A
- Connection method: Push-in spring connection
- Conductor cross section: 0.2 mm² to 2.5 mm² (AWG 24 to 12)
- Stripping length: 10 mm
- Dimensions: Length 23.7 mm, Width 50.62 mm, Height 14.3 mm
- Material: Tin-plated, contact surface
- Environmental compliance: China RoHS
Buy the Phoenix Contact Series FKCOR 8-Pole Connector: FKCOR258STF508
Purchase the Phoenix Contact FKCOR 2,5/8-STF-5,08 connector online today to ensure robust industrial connections. This 8-pole female connector with a 5.08 mm pitch provides secure, tool-free push-in wiring, enhanced stability via screw flange, and support for solid conductors from 0.2 to 2.5 mm². Rated for voltages up to 630V and currents of 12A, its design simplifies assembly for DIN-rail applications and is compatible with the MSTB 2,5 range. Ideal for efficient and reliable electrical installations.
Get Phoenix Contact FKCOR258STF508 today—built for reliable industrial connectivity and quick installation.
Frequently Asked Questions
Where can I buy Phoenix Contact FKCOR258STF508?
You can click on the BUY or RFQ button to purchase FKCOR258STF508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FKCOR258STF508?
You can download the FKCOR258STF508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FKCOR258STF508?
Phoenix Contact
