Phoenix Contact FKMCP152ST35LR PCB Connector
The FK-MCP 1,5/2-ST-3,5-LR is a 2-position printed-circuit board connector suitable for efficient PCB wiring. Featuring push-in spring connections, it ensures fast, tool-free installation with stable contact force for long-term reliability. Made with high-quality PA insulation with UL 94V-0 flammability rating, it supports rated voltages up to 160V and nominal currents of 8A. Its compact design measures 27.4mm in length, 14.22mm in height, and 14.04mm in width, making it ideal for space-constrained applications, with tin-plated contacts for excellent conductivity.
Phoenix Contact FKMCP152ST35LR PCB Connector Specifications:
- Number of positions: 2
- Connection method: Push-in spring connection
- Rated voltage: 160V (III/2), 320V (II/2)
- Rated current: 8A
- Insulating material: PA (Polyamide), UL 94V-0 flammability rating
- Contact surface: Tin
- Dimensions: Length 27.4mm, Height 14.22mm, Width 14.04mm
- Pitch: 3.5mm
- Stripping length: 9mm
- Conductor cross section: solid 0.14–1.5 mm², flexible 0.14–1.5 mm²
- Maximum conductor cross section with ferrule: 1.5 mm²
- Conductor wire range: AWG 26–16
- Flammability rating: UL 94V-0
- Standards: EN-VDE, UL, cULus Recognized
- Operating temperature: Included in typical product data
- Mounting: Wave soldering compatible
Buy the Buy Phoenix Contact PCB Connector Part Number FKMCP152ST35LR Online
Secure your electronic assemblies with the Phoenix Contact FK-MCP 1,5/2-ST-3,5-LR connector. This 2-position PCB connector features push-in spring terminals for quick, tool-free wiring, ensuring a stable contact force for long-lasting performance. Made from UL 94V-0 rated PA material, it supports voltages up to 160V and currents of 8A, compactly measuring 27.4mm in length. Its tin-plated contacts provide excellent electrical conductivity, making it ideal for reliable, space-saving industrial and electronic applications.
Get Phoenix Contact FK-MCP 1,5/2-ST-3,5-LR today—designed for reliable PCB connections with easy push-in installation and long-term stability.
Frequently Asked Questions
Where can I buy Phoenix Contact FKMCP152ST35LR?
You can click on the BUY or RFQ button to purchase FKMCP152ST35LR from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FKMCP152ST35LR?
You can download the FKMCP152ST35LR datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FKMCP152ST35LR?
Phoenix Contact
