Phoenix Contact FRONTMC155ST381 Printed Circuit Board Connector
The PHOENIX CONTACT FRONT-MC 1,5/ 5-ST-3,81 is a versatile printed circuit board connector designed for secure and efficient connections. Its front screw connection simplifies the assembly process, while the generously dimensioned wiring space ensures ease of use. The connector supports a nominal current of 8A and a rated voltage of 160V, making it suitable for a wide range of industrial applications. Individual position coding is possible by removing the coding tab and connecting the coding profile to the header, enhancing circuit reliability. This connector is a key component in various electronic assemblies, providing a robust and dependable connection solution.
Phoenix Contact FRONTMC155ST381 Printed Circuit Board Connector Specifications:
- Nominal current: 8 A
- Rated voltage (III/2): 160 V
- Number of positions: 5
- Pitch: 3.81 mm
- Connection method: Front screw connection
- Color: green
- Contact surface: Tin
- Insulating material group: I
- Rated surge voltage (III/3): 2.5 kV
- Rated surge voltage (III/2): 2.5 kV
- Rated surge voltage (II/2): 2.5 kV
- Rated voltage (III/3): 160 V
- Rated voltage (II/2): 320 V
- Connection in acc. with standard: EN-VDE
- Nominal cross section: 1.5 mm²
- Maximum load current: 8 A (with 1.5 mm² conductor cross section)
- Insulating material: PA
- Flammability rating according to UL 94: V0
- Stripping length: 9 mm
- Tightening torque, min: 0.22 Nm
- Tightening torque max: 0.25 Nm
- Conductor cross section solid min.: 0.14 mm²
- Conductor cross section solid max.: 1.5 mm²
- Conductor cross section flexible min.: 0.14 mm²
- Conductor cross section flexible max.: 1.5 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 1.5 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve max.: 0.5 mm²
- Conductor cross section AWG min.: 28
- Conductor cross section AWG max.: 16
- Packing unit: 1 pc
- Country of origin: Germany
- Custom tariff number: 85366990
- Weight per Piece (excluding packing): 6.73 g
Buy the FRONT-MC 1 5/ 5-ST-3 81 PHOENIX CONTACT Printed Circuit Board Connector | myMectronic
Purchase the PHOENIX CONTACT FRONT-MC 1,5/ 5-ST-3,81 online for a secure and reliable connection solution.
Buy Now
Frequently Asked Questions
Where can I buy Phoenix Contact FRONTMC155ST381?
You can click on the BUY or RFQ button to purchase FRONTMC155ST381 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FRONTMC155ST381?
You can download the FRONTMC155ST381 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FRONTMC155ST381?
Phoenix Contact
