Phoenix Contact FRONTMSTB258STF508 PCB Connector
The FRONT-MSTB 2.5/8-STF-5.08 is a printed-circuit board connector designed for efficient and reliable connections in compact electronic assemblies. It features a front screw connection method, 8 positions with a 5.08 mm pitch, and is made of durable PA insulation material. The contact surface is tin-plated for optimal conductivity. Rated for 12 A and 320 V in standard EN-VDE, it supports solid and stranded conductors with flexible ferrules. Its robust design ensures secure connections even in tight spaces, making it ideal for automation and control applications.
Phoenix Contact FRONTMSTB258STF508 PCB Connector Specifications:
- Number of positions: 8
- Pitch: 5.08 mm
- Rated current: 12 A
- Rated voltage: 320 V in standard EN-VDE
- Connection method: Front screw connection
- Insulating material: PA
- Contact surface: Tin-plated
- Dimensions: Length 18.9 mm, Height 15 mm, Width 50.44 mm
- Screw thread: M25
- Tightening torque: 0.5 Nm to 0.6 Nm
- Conductor cross section: solid 0.34-2.5 mm², flexible 0.2-2.5 mm²
- Conductor AWG: 24-12
- Flammability rating: UL 94 V0
- Standards compliance: EN-VDE
- Mounting: Wave soldering or press-in technology
- Rated surge voltage: 4 kV
Buy the Phoenix Contact Series ED PCB Connector: FRONT-MSTB 2,5/8-STF-5,08
Enhance your electronic projects with the Phoenix Contact FRONT-MSTB 2,5/8-STF-5,08 PCB connector, offering reliable 8-position connection, front screw terminal, rated for 12 A and 320 V. Its robust PA insulation with tin-plated contacts ensures secure, corrosion-resistant connections. Designed for tight installation spaces, it features a 5.08 mm pitch and versatile mounting options, including wave soldering and press-in. Perfect for automation and control systems, this connector guarantees durability, safety, and high-performance connectivity for professional electronic applications.
Buy Phoenix Contact FRONT-MSTB 2,5/8-STF-5,08 now and experience unmatched reliability and performance in your electronic assemblies.
