Phoenix Contact GMKDS33762 PCB Terminal Block
The PCB terminal block GMKDS 3/3-7.62 offers a reliable screw connection with tension sleeve, supporting up to 24 A and 630 V. Its 7.62 mm pitch and three positions facilitate easy wiring and secure conductor attachment, making it suitable for wave soldering and various industrial applications. Its durable PA insulation, UL 94V-0 flammability rating, and compatibility with a wide range of conductor sizes (0.2-4 mm² solid; 0.2-2.5 mm² flexible) enhance safety, performance, and versatility. The terminal features a screw thread M3, tightening torque between 0.5-0.6 Nm, and complies with EN-VDE and UL standards.
Phoenix Contact GMKDS33762 PCB Terminal Block Specifications:
- Dimensions: Length 11.2 mm, Width 22.86 mm, Construction height 13.8 mm, Height 18.9 mm, Dimension a 15.24 mm, Length of solder pin 5.1 mm, Hole diameter 1.3 mm
- Material: PA, Flammability rating UL 94V-0, Sn plated solder pins, Insulating material group 1
- Electrical: Nominal current 24 A, Nominal voltage 630 V, Rated surge voltage 6 kV, Rated voltage ranges from 300 V to 1000 V based on standard, Max load current 30 A with 4 mm² conductor
- Connection: Screw thread M3, Tightening torque 0.5-0.6 Nm, Conductor cross section solid 0.2-4 mm², flexible 0.2-2.5 mm², AWG 24-12, Compatible with ferrules and twin ferrules
- Standards & Approvals: EN-VDE, UL Recognized, CSA, cUL Recognized, EAC, DNV GL, SEV Approval, flammability UL 94V-0, Environmentally compliant with China RoHS
Buy the Buy Phoenix Contact PCB Terminal Block GMKDS 3/3-7.62 Part Number GMKDS33762 Online
Purchase the Phoenix Contact PCB Terminal Block GMKDS 3/3-7.62 online today. This high-quality, reliable terminal block is designed for secure connections supporting up to 24 A and 630 V. Its 7.62 mm pitch and three positions make wiring straightforward and safe. Made with durable PA insulation and recognized standards, it ensures safety and performance in industrial environments. With easy installation, compatibility with various conductor sizes, and UL/EN-VDE certifications, this terminal block is essential for reliable electronic and control systems. Order now for fast delivery and assured quality.
Get Phoenix Contact GMKDS 3/3-7.62 today—designed for secure wiring, high reliability, and industrial-grade durability in electronics applications.
Frequently Asked Questions
Where can I buy Phoenix Contact GMKDS33762?
You can click on the BUY or RFQ button to purchase GMKDS33762 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part GMKDS33762?
You can download the GMKDS33762 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of GMKDS33762?
Phoenix Contact
