Phoenix Contact GMSTB25HCV12ST762 Plug Terminal Block
The Phoenix Contact GMSTB 2,5 HCV/12-ST-7,62 plug terminal block offers a reliable and space-saving solution for connecting wires in industrial environments. Its compact 7.62 mm pitch maximizes density, while the double steel spring ensures secure and stable connections even under fluctuating temperatures and power conditions. With a nominal current of 16A and a rated voltage of 1000V, this terminal block is suitable for a wide range of applications, including power distribution, control circuits, and automation systems. The tin-plated contact surface provides excellent conductivity and corrosion resistance, ensuring long-term performance and reliability. Its UL approval and EAC certification further validate its quality and compliance with international standards.
Phoenix Contact GMSTB25HCV12ST762 Plug Terminal Block Specifications:
- Nominal current: 16 A
- Rated voltage (III/2): 1000 V
- Number of positions: 12
- Pitch: 7.62 mm
- Connection method: Screw connection with tension sleeve
- Color: green
- Contact surface: Tin
- Packing unit: 1 pc
- Minimum order quantity: 50 pc
- Weight per Piece (excluding packing): 24.1 g
- Custom tariff number: 85366990
- Country of origin: Germany
- Width: 91.22 mm
- Dimension a: 83.82 mm
- Insulating material group: I
- Rated surge voltage (III/3): 8 kV
- Rated surge voltage (II/2): 8 kV
- Rated voltage (III/3): 1000 V
- Rated voltage (II/2): 1000 V
- Connection in acc. with standard: EN-VDE
- Nominal cross section: 2.5 mm²
- Maximum load current: 16 A
- Insulating material: PA
- Flammability rating according to UL 94: V0
- Internal cylindrical gage: A3
- Stripping length: 8 mm
- Screw thread: M3
- Tightening torque, min: 0.5 Nm
- Tightening torque max: 0.6 Nm
- Conductor cross section solid min.: 0.2 mm²
- Conductor cross section solid max.: 2.5 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 2.5 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 2.5 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve max.: 2.5 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 12
- 2 conductors with same cross section, solid min.: 0.2 mm²
- 2 conductors with same cross section, solid max.: 1 mm²
- 2 conductors with same cross section, stranded min.: 0.2 mm²
- 2 conductors with same cross section, stranded max.: 1.5 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve, min.: 0.25 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve, max.: 1 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min.: 0.5 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max.: 1 mm²
- Minimum AWG according to UL/CUL: 30
- Maximum AWG according to UL/CUL: 12
