Phoenix Contact GMSTB25HCV2ST762 2.5mm Screw Terminal Plug
The Phoenix Contact GMSTB 2.5 HCV/ 2-ST-7.62 is a versatile plug connector ideal for applications requiring robust and dependable power distribution. Its well-known connection principle ensures worldwide usability, while the low temperature rise and integrated double steel spring provide enhanced safety and stability. This connector is particularly useful in industrial automation, control systems, and power supply applications where reliable connections are paramount. It is designed to accommodate conductors with varying cross-sections and offers excellent insulation properties with a V0 flammability rating.
Phoenix Contact GMSTB25HCV2ST762 2.5mm Screw Terminal Plug Specifications:
- Nominal current: 16 A
- Rated voltage (III/2): 1000 V
- Number of positions: 2
- Pitch: 7.62 mm
- Connection method: Screw connection
- Color: green
- Contact surface: Tin
- Packing unit: 1 pc
- Minimum order quantity: 50 pc
- Weight per Piece (excluding packing): 4.47 g
- Custom tariff number: 85366990
- Country of origin: Germany
- Width: 15.02 mm
- Dimension a: 7.62 mm
- Insulating material group: I
- Rated surge voltage (III/3): 8 kV
- Rated surge voltage (II/2): 6 kV
- Rated voltage (III/3): 1000 V
- Rated voltage (II/2): 1000 V
- Connection in acc. with standard: EN-VDE
- Nominal cross section: 2.5 mm²
- Maximum load current: 16 A
- Insulating material: PA
- Flammability rating according to UL 94: V0
- Internal cylindrical gage: A3
- Stripping length: 8 mm
- Screw thread: M3
- Tightening torque, min: 0.5 Nm
- Tightening torque max: 0.6 Nm
- Conductor cross section solid min.: 0.2 mm²
- Conductor cross section solid max.: 2.5 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 2.5 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 2.5 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve max.: 2.5 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 12
- 2 conductors with same cross section, solid min.: 0.2 mm²
- 2 conductors with same cross section, solid max.: 1 mm²
- 2 conductors with same cross section, stranded min.: 0.2 mm²
- 2 conductors with same cross section, stranded max.: 1.5 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve, min.: 0.25 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve, max.: 1 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min.: 0.5 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max.: 1 mm²
- Minimum AWG according to UL/CUL: 30
- Maximum AWG according to UL/CUL: 12
- eCl@ss 4.0: 272607xx
- eCl@ss 4.1: 27260701
- eCl@ss 5.0: 27260701
- eCl@ss 5.1: 27260701
- eCl@ss 6.0: 27260704
- eCl@ss 7.0: 27440402
- eCl@ss 8.0: 27440309
- ETIM 3.0: EC001121
- ETIM 4.0: EC002638
- ETIM 5.0: EC002638
- UNSPSC 6.01: 30211810
- UNSPSC 7.0901: 39121409
- UNSPSC 11: 39121409
- UNSPSC 12.01: 39121409
- UNSPSC 13.2: 39121409
Buy the GMSTB 2 5 HCV/ 2-ST-7 62 PHOENIX CONTACT 2.5mm Screw Terminal Plug | myMectronic
Purchase the Phoenix Contact GMSTB 2 5 HCV/ 2-ST-7 62 plug connector securely online for your industrial needs.
Buy Now
Frequently Asked Questions
Where can I buy Phoenix Contact GMSTB25HCV2ST762?
You can click on the BUY or RFQ button to purchase GMSTB25HCV2ST762 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part GMSTB25HCV2ST762?
You can download the GMSTB25HCV2ST762 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of GMSTB25HCV2ST762?
Phoenix Contact
