Phoenix Contact GMVSTBR252ST762 PCB connector
This is a printed-circuit board connector featuring a 2-position configuration with a 7.62 mm pitch, designed for reliable electrical connections in industrial automation. It utilizes screw connection with tension sleeve for secure attachment, rated for 12 A current and 630 V voltage. Made from flame-retardant PA, it supports a wide range of wire sizes, including solid and stranded conductors, with a stripping length of 7 mm. Suitable for various standard compliance requirements, ensuring durable performance in demanding environments.
Phoenix Contact GMVSTBR252ST762 PCB connector Specifications:
- Range of articles: GMVSTBR 2.5/..-ST
- Type of contact: Female connector
- Number of positions: 2
- Connection method: Screw connection with tension sleeve
- Insulating material: PA
- Flammability rating: UL 94 VO
- Rated surge voltage: 6kV
- Rated voltage: 630 V (III/2), 500 V (III/3), 1000 V (IV/2)
- Nominal current: 12 A
- Nominal cross section: 2.5 mm²
- Maximum load current: 12 A
- Screw thread: M3
- Tightening torque: 0.5 - 0.6 Nm
- Conductor cross section: solid 0.2-2.5 mm², flexible 0.2-2.5 mm²
- AWG: 24-12
- Cable stripping length: 7 mm
- Environmental: Environmentally friendly, RoHS compliant
- Dimensions: Length 245.58 mm, Pitch 7.62 mm, contact surface: Tin, mounting: Wave soldering
Buy the Phoenix Contact GMVSTBR 2-ST Reliable PCB Connector for Industrial Applications
Purchase the Phoenix Contact GMVSTBR 2-ST-7,62 PCB connector online today and benefit from quick delivery and guaranteed compatibility. Designed for demanding industrial environments, it offers secure screw termination with tension sleeve, rated 12 A and 630 V, supporting a wide range of wire sizes. The flame-retardant PA material ensures safety and durability, while the 7.62 mm pitch enables compact wiring. Ideal for automation systems and control panels, this connector guarantees reliable electrical contacts in your projects. Order now for dependable quality and fast fulfillment.
Order your Phoenix Contact GMVSTBR 2-ST-7,62 connector today and ensure reliable, secure connections for your industrial wiring projects.
Frequently Asked Questions
Where can I buy Phoenix Contact GMVSTBR252ST762?
You can click on the BUY or RFQ button to purchase GMVSTBR252ST762 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part GMVSTBR252ST762?
You can download the GMVSTBR252ST762 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of GMVSTBR252ST762?
Phoenix Contact
