Phoenix Contact IC253G508 PCB Connector
The IC 2.5/3-G-5.08 base strip is a compact, wave solderable PCB connector with three positions and a pitch of 5.08 mm. Made from durable PA insulating material with a tin contact surface, it is rated for 12A current and 320V voltage. Suitable for industrial applications requiring reliable, shock-proof connections, it complies with standards such as EN-VDE, UL, CSA, and VDE. Ideal for circuit board assembly, it features a green color for easy identification and mounting flexibility including wave soldering.
Phoenix Contact IC253G508 PCB Connector Specifications:
- Rated current: 12 A
- Rated voltage: 320 V (III/2)
- Number of positions: 3
- Pitch: 5.08 mm
- Length: 18.9 mm
- Width: 17.24 mm
- Constructional height: 10.2 mm
- Height: 13.7 mm
- Solder pin length: 3.5 mm
- Pin dimensions: 0.48 x 1.14 mm
- Hole diameter: 1.4 mm
- Contact surface: Tin
- Insulating material: PA
- Flammability rating: UL 94 V-0
- Connection in accordance with standards: EN-VDE, CSA, UL recognitions
- Rated surge voltage: 4 kV
- Ambient temperature range: -40°C to +85°C
Buy the Buy Phoenix Contact IC 2.5/3-G-5.08 Part Number IC253G508 Online
Purchase the Phoenix Contact PCB connector IC 2.5/3-G-5.08 online today to secure a reliable, high-quality connection for industrial and PCB applications. With a compact design, 3 positions, 5.08 mm pitch, and rated for 12A and 320V, this wave solderable connector features tin contact surfaces and complies with UL, CSA, and EN-VDE standards. Its durable PA insulating material and green color make it ideal for a variety of electrical systems, ensuring safety, ease of installation, and long-term performance in demanding environments.
Buy Phoenix Contact IC 2.5/3-G-5.08 now and experience unmatched reliability and performance in PCB connection solutions.
Frequently Asked Questions
Where can I buy Phoenix Contact IC253G508?
You can click on the BUY or RFQ button to purchase IC253G508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part IC253G508?
You can download the IC253G508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of IC253G508?
Phoenix Contact
