Phoenix Contact IC256STGF508 PCB Connector
The printed-circuit board connector IC 2.5/6-STGF-5.08 is designed for reliable industrial PCB connections with six positions, a pitch of 5.08 mm, and rated for 12 A and 320 V. It features a screw connection with tension sleeve, tin contact surface, and robust insulation from PA material. This connector ensures easy PCB replacement, mechanical stability via screwable flange, and compatibility with various accessories like insertion bridges and coding elements. Ideal for automation and control panels requiring secure, durable electrical connections.
Phoenix Contact IC256STGF508 PCB Connector Specifications:
- Number of positions: 6
- Pitch: 5.08 mm
- Rated current: 12 A
- Rated voltage: 320 V
- Connection method: Screw connection with tension sleeve
- Contact surface: Tin
- Insulating material: PA
- Screw thread: M3
- Tightening torque: 0.5 to 0.6 Nm
- Suitable for conductor cross section: 0.2 to 2.5 mm²
- Flammability rating: UL 94 V-0
- Maximum load current: 12A
- Minimum conductor AWG: 24
- Maximum conductor AWG: 12
- Conductor stripping length: 7 mm
Buy the Phoenix Contact IC 2,5/6-STGF-5,08 – Reliable PCB Connectors for Industrial Applications
Enhance your industrial projects with the Phoenix Contact PCB connector featuring 6 positions, a 5.08 mm pitch, and rated for 12 A at 320 V. This robust connector is ideal for secure, durable PCB connections, offering easy installation with screw connection technology and tin contact surface for reliable conductivity. Its high-quality PA insulation ensures safety and longevity in demanding environments. Compatible with various accessories, it provides flexibility and efficiency for automation, machinery, and control systems. Purchase online today for quick deployment and professional-grade performance.
Order your Phoenix Contact IC 2,5/6-STGF-5,08 today and equip your control systems with dependable, easy-to-install PCB connectors designed for industrial environments.
Frequently Asked Questions
Where can I buy Phoenix Contact IC256STGF508?
You can click on the BUY or RFQ button to purchase IC256STGF508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part IC256STGF508?
You can download the IC256STGF508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of IC256STGF508?
Phoenix Contact
