Phoenix Contact MC153GF381 Base strip
This is a green 3-position base strip with a pitch of 3.81 mm designed for reliable electrical connections. Made from insulating PBT material with a tin contact surface, it provides a rated voltage of 160 V and a nominal current of 8 A. Suitable for wave soldering mounting, the base strip enhances device flexibility with a well-known mounting principle and robust mechanical stability via screwable flange. Ideal for modular systems and device design requiring versatile connection options and durable performance in industrial automation applications.
Phoenix Contact MC153GF381 Base strip Specifications:
- Number of positions: 3
- Pitch: 3.81 mm
- Rated voltage: 160 V
- Nominal current: 8 A
- Material: PBT
- Contact surface: Tin
- Mounting: Wave soldering
- Color: Green
- Dimensions: Length 9.2 mm, Width 21.82 mm, Constructional height 6.9 mm
- Hole diameter: 1.2 mm
- Flammability rating: UL 94V-0
- Standards: EN-VDE, CSA, cULus recognition
- Rated surge voltage: 2.5 kV
- Temperature rating: -55°C to +105°C
Buy the Buy Phoenix Contact Base Strip MC 1,5/ 3-GF-3,81 Part Number MC153GF381 Online
Purchase the Phoenix Contact base strip MC 1,5/ 3-GF-3,81 online today for dependable electrical connections in industrial automation. Featuring three positions, a 3.81 mm pitch, and rated for 8 A at 160 V, it is crafted from durable PBT with a tin contact surface that guarantees longevity and stable performance. Designed for wave soldering, it offers excellent mechanical stability with a screwable flange. Ideal for modular device construction requiring reliable, flexible wiring compatible with various connection technologies.
Buy Phoenix Contact MC 1,5/ 3-GF-3,81 base strip now and ensure robust, reliable connections with high-quality industrial automation components.
