Phoenix Contact MC154G508 Terminal Base Strip
The MC 1.5/4-G-5.08 is a versatile base strip designed for reliable connection and switching applications in electrical panels and control systems. It features four positions, a pitch of 5.08 mm, and a rated current of 8 A, rated voltage of 320 V. Made from PBT with tin-plated contact surfaces, it ensures durability and efficient conductivity. Suitable for wave soldering, this green-colored component complies with UL 94V-0 flammability standards, making it ideal for industrial automation and device design requiring flexible, robust terminal connection solutions.
Phoenix Contact MC154G508 Terminal Base Strip Specifications:
- Number of positions: 4
- Pitch: 5.08 mm
- Rated current: 8 A
- Rated voltage (III/2): 320 V
- Material: PBT with tin-plated contact surface
- Color: Green
- Flammability rating: UL 94V-0
- Dimensions: Length 15.24 mm, Width 20.32 mm, Constructional height 7.25 mm, Hole diameter 3.4 mm
- Pin length: 9.2 mm
- Standards: EN-VDE, CSA, UL recognized
- Maximum load current: 8 A
- Rated surge voltage: 4 kV
- Environmental compliance: China RoHS, unlimited use period (EFUP)
Buy the Buy Phoenix Contact MC 1,5/4-G-5,08 Part Number MC154G508 Online
Purchase the Phoenix Contact MC 1,5/4-G-5,08 base strip online today and ensure your electrical assemblies are built with a durable, standardized terminal strip. This versatile component features four positions with a pitch of 5.08 mm, rated at 8 A and 320 V, suitable for wave soldering. Made from high-quality PBT with tin-plated contact surfaces, it complies with UL 94V-0 flammability standards. Ideal for industrial automation, it guarantees dependable performance, flexible device design, and effortless installation, making it the perfect choice for your wiring and connection needs.
Order your Phoenix Contact MC 1,5/4-G-5,08 base strip today and enhance your control panel connectivity with a reliable, industry-standard component designed for high performance.
Frequently Asked Questions
Where can I buy Phoenix Contact MC154G508?
You can click on the BUY or RFQ button to purchase MC154G508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part MC154G508?
You can download the MC154G508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of MC154G508?
Phoenix Contact
