Phoenix Contact MCDV156G381 PCB Base Strip
This is a green base strip suitable for PCB mounting with 6 positions and a pitch of 3.81 mm. It supports a nominal current of 8 A and rated voltage of 160 V in accordance with EN standards, and features a tin contact surface. The strip is made from PA insulation material, flammability rated UL 94 VO, and designed for wave soldering mounting. Its dimensions are length 22.7 mm, width 24.25 mm, with a pin length of 3.4 mm and pin spacing of 15.24 mm. Approved under VDE, UL, CSA, and IEC standards, ensuring quality and safety.
Phoenix Contact MCDV156G381 PCB Base Strip Specifications:
- Dimensions: Length 22.7 mm, Width 24.25 mm, Construction height 21.9 mm, Height 25.3 mm, Pin length 3.4 mm, Pin spacing 15.24 mm
- Material: PA (Polyamide), Contact surface: Tin
- Rated current: 8 A, Nominal voltage: 160 V (EN/IEC standard)
- Flammability rating: UL 94 VO, Insulating material group 1
- Number of positions: 6, Pitch: 3.81 mm
- Mounting: Wave soldering compatible, Connection types: In accordance with EN-VDE standard
- Approvals: VDE, UL, CSA, EAC, China RoHS
- Color: Green
- Rated surge voltage: 25 kV (III/2), 2.5 kV (II/3)
- Dimensions: Hole diameter 1.2 mm
Buy the Phoenix Contact MCDV156G381 – Reliable PCB Base Strip for Industrial Applications
Purchase the Phoenix Contact MCDV156G381 base strip now and enhance your industrial projects with a high-quality, reliable PCB connection component. This 6-position base strip with a 3.81 mm pitch is designed for efficient wave soldering and provides a durable connection with proven safety certifications. Its compact size, UL-rated flammability, and compliance with international standards make it the ideal choice for diverse electronics and PCB assembly tasks. Order online today for fast, secure delivery and seamless integration into your manufacturing process.
Order your Phoenix Contact Series MCDV156G381 base strip today and ensure stable, reliable connections in your PCB designs with superb flexibility and compliance.
