Phoenix Contact MDSTB253G1508 Base Strip Connector
The MDSTB 2,5/ 3-G1-5,08 is a versatile green base strip designed for reliable PCB connections in electrical and automation applications. With a pitch of 5.08 mm and three positions, it meets industry standards for safety and performance, rated for 10 A and 320 V. Made of flame-retardant PA material, it supports wave soldering and provides high contact density with multiple connection levels. Compatible with MVSTB or FKCV plug components, it offers flexible device design options and easy PCB replacement, ensuring dependable electrical connectivity across various industries.
Phoenix Contact MDSTB253G1508 Base Strip Connector Specifications:
- Material: PA (polyamide)
- Color: Green
- Number of Positions: 3
- Pitch: 5.08 mm
- Dimensions: Length 22 mm, a 10.16 mm, construction height 29 mm
- Solder Pin Length: 3.5 mm
- Pin Dimensions: 1 x 1 mm
- Hole Diameter: 1.4 mm
- Rated Current: 10 A
- Rated Voltage: 320 V (III/2)
- Maximum Load Current: 10 A per position
- Flammability Rating: UL 94 V-0
- Connection Standard: EN-VDE
- Insulating Material Group: PA
- Rated Surge Voltage: 4 kV (III/3)
Buy the Buy Phoenix Contact Base Strip MDSTB 2,5/ 3-G1-5,08 Online
Unlock the reliable electrical connection with the Phoenix Contact MDSTB 2,5/ 3-G1-5,08 base strip. Perfectly suited for automation, industrial equipment, and electronic circuit boards, this versatile connector offers three connection positions, supports wave soldering, and provides high contact density for compact design. Made of flame-retardant PA material in green, rated for 10 A and 320 V, it guarantees safety, durability, and performance in demanding environments. Ensure seamless PCB replacements and flexible device configurations by purchasing online today.
Order your Phoenix Contact MDSTB 2,5/ 3-G1-5,08 base strip today and enhance your device design with reliable PCB connections and high contact density.
Frequently Asked Questions
Where can I buy Phoenix Contact MDSTB253G1508?
You can click on the BUY or RFQ button to purchase MDSTB253G1508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part MDSTB253G1508?
You can download the MDSTB253G1508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of MDSTB253G1508?
Phoenix Contact
