Phoenix Contact MSTBA2511G508LR PCB Connector
The MSTBA 2,5/11-G-5,08-LR is a printed-circuit board connector designed for reliable, flexible device connections. It features 11 positions with a 5.08 mm pitch, made from environmentally friendly PBT material, and has a rated voltage of 320V with a nominal current of 12A. It is suitable for wave soldering and complies with EN-VDE standards. Its green color and tin contact surface ensure durability and safety for various electronic applications, offering secure locking and easy release with intuitive operation.
Phoenix Contact MSTBA2511G508LR PCB Connector Specifications:
- Number of positions: 11
- Pitch: 5.08 mm
- Rated voltage: 320 V (III/2), 250 V (III/3), 400 V (II/2)
- Rated current: 12 A
- Contact surface: Tin
- Material: PBT insulating material
- Mounting: Wave soldering
- Flammability rating: UL 94 VO
- Color: Green
- Insulating material group: Mla
- Maximum surge voltage: 4 kV
- Nominal current: 12 A
- Connection standard: EN-VDE
- Weight per piece: 5.100 g
- Country of origin: Germany
Buy the Phoenix Contact Series MSTBA PCB Connector: MSTBA2511G508LR
Secure your electronic assemblies with the Phoenix Contact PCB Connector, featuring 11 positions, 5.08 mm pitch, and rated for 12A at 320V. Crafted from durable PBT plastic, it offers excellent mechanical stability, UL 94 VO flammability rating, and easy wave soldering mounting. Its twist-lock mechanism ensures safe, reliable connections, while the green color indicates clearly identifiable wiring points. Perfect for industrial and automation applications, this connector meets EN-VDE standards, complies with environmental regulations, and is available for quick online purchase, ensuring efficient project completion.
Buy Phoenix Contact MSTBA2511G508LR now and experience unmatched reliability and performance in your electronic device connections.
Frequently Asked Questions
Where can I buy Phoenix Contact MSTBA2511G508LR?
You can click on the BUY or RFQ button to purchase MSTBA2511G508LR from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part MSTBA2511G508LR?
You can download the MSTBA2511G508LR datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of MSTBA2511G508LR?
Phoenix Contact
