Phoenix Contact SLKK5 Double Level Terminal Block
The Phoenix Contact SLKK 5 double-level terminal block provides a compact and organized solution for connecting multiple circuits. Its three-level design allows for efficient use of space, making it ideal for applications with limited room. The screw connection ensures a secure and reliable connection, while the gray color provides clear visual identification. This terminal block is particularly well-suited for controllers with external actuating drives, solenoid valves, and limit switches, offering a convenient way to connect return lines and LEDs to a common busbar. It simplifies wiring and enhances the overall organization of electrical systems.
Phoenix Contact SLKK5 Double Level Terminal Block Specifications:
- Number of levels: 3
- Number of connections: 5
- Nominal cross section: 4 mm²
- Color: gray
- Insulating material: PA
- Flammability rating according to UL 94: V0
- Rated surge voltage: 6 kV
- Degree of pollution: 3
- Overvoltage category: III
- Insulating material group: I
- Connection in acc. with standard: IEC 60947-7-1 / IEC 60947-7-2
- Nominal current IN: 34 A
- Maximum load current: 34 A (with 4 mm² conductor cross section)
- Nominal voltage UN: 500 V
- Open side panel: Yes
- Conductor cross section solid min.: 0.2 mm²
- Conductor cross section solid max.: 4 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 4 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 10
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 4 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve max.: 2.5 mm²
- Cross section with insertion bridge, solid max.: 4 mm²
- Cross section with insertion bridge, stranded max.: 2.5 mm²
- 2 conductors with same cross section, solid min.: 0.2 mm²
- 2 conductors with same cross section, solid max.: 1.5 mm²
- 2 conductors with same cross section, stranded min.: 0.2 mm²
- 2 conductors with same cross section, stranded max.: 1.5 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve, min.: 0.25 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve, max.: 1.5 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min.: 0.5 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max.: 1.5 mm²
- Stripping length: 8 mm
- Internal cylindrical gage: A3
- Screw thread: M3
- Tightening torque, min: 0.6 Nm
- Tightening torque max: 0.8 Nm
- Packing unit: 1 pc
- Weight per Piece (excluding packing): 22.8 g
- Custom tariff number: 85369010
- Country of origin: Poland
- eCl@ss 4.0: 27141118
- eCl@ss 4.1: 27141118
- eCl@ss 5.0: 27141118
- eCl@ss 5.1: 27141118
- eCl@ss 6.0: 27141125
- eCl@ss 7.0: 27141125
- eCl@ss 8.0: 27141125
- ETIM 2.0: EC001329
- ETIM 3.0: EC001329
- ETIM 4.0: EC001329
- ETIM 5.0: EC001329
- UNSPSC 6.01: 30211811
- UNSPSC 7.0901: 39121410
- UNSPSC 11: 39121410
- UNSPSC 12.01: 39121410
- UNSPSC 13.2: 39121410
