Phoenix Contact SMKDS1635 PCB Terminal Block
The PCB terminal block SMKDS 1/6-3.5 offers reliable screw connection with tension sleeve, suitable for wave soldering, with a 3.5 mm pitch and 6 positions. It features a compact design, angled connection for multi-row arrangements, and is made of PA insulation material. Rated for 10 A and 200 V, it complies with EN-VDE standards, with a maximum surge voltage of 2.5 kV. The device has a length of 10 mm, width of 21.5 mm, and a height of 13 mm, making it ideal for efficient, space-saving PCB connections.
Phoenix Contact SMKDS1635 PCB Terminal Block Specifications:
- Number of positions: 6
- Pitch: 3.5 mm
- Rated current: 10 A
- Rated voltage: 200 V
- Maximum load current: 12 A
- Connection method: Screw with tension sleeve
- Screw thread: M2
- Tightening torque: 0.22-0.25 Nm
- Conductor cross section: solid 0.14-1.5 mm², flexible 0.14-1 mm²
- Stripping length: 5 mm
- Pin dimensions: 0.5 x 0.9 mm
- Dimension a: 17.5 mm
- Length: 10 mm
- Width: 21.5 mm
- Constructional height: 9.5 mm
- Height: 13 mm
- Insulating material: PA
- Flammability rating: UL 94 V0
- Certifications: EN-VDE, CSA, UL, cULus
- Rated surge voltage: 2.5 kV
Buy the Phoenix Contact Series SMKDS PCB Terminal Block 6-Position: SMKDS1635
Purchase the Phoenix Contact Series SMKDS 1/6-3.5 PCB terminal block online today to benefit from high-quality, space-saving connection solutions. Designed with screw terminals and tension sleeves for secure contact, this 6-position device features a 3.5 mm pitch, rated at 10 A and 200 V, ideal for various PCB wiring applications. Its compact size, compliance with international standards, and reliable performance make it a perfect choice for engineers and technicians seeking durable and efficient connection components for complex electronic assemblies.
Order your Phoenix Contact Series SMKDS 1/6-3.5 PCB terminal block today and ensure reliable, space-efficient PCB connections for your projects.
Frequently Asked Questions
Where can I buy Phoenix Contact SMKDS1635?
You can click on the BUY or RFQ button to purchase SMKDS1635 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part SMKDS1635?
You can download the SMKDS1635 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of SMKDS1635?
Phoenix Contact
