Phoenix Contact SPTAF1535LL PCB Terminal Block
The PCB terminal block SPTAF 1/5-3,5-LL is a compact, space-saving connection component designed for reliable electrical connections in automation and control panels. It features a push-in spring connection system that allows for quick, tool-free wiring, ensuring long-term contact stability. With 5 positions, a 3.5 mm pitch, and a rated current of 13.5 A at 160 V, it supports a conductor cross section from 0.2 mm² to 1 mm². Its wave soldering-compatible design and integrated test options make it ideal for industrial applications demanding efficiency and ease of maintenance.
Phoenix Contact SPTAF1535LL PCB Terminal Block Specifications:
- Rated surge voltage: 25kV
- Rated voltage: 160 V
- Rated current: 13.5 A
- Number of positions: 5
- Pitch: 3.5 mm
- Conductor cross section: 0.2 mm² - 1 mm² (AWG 24-18)
- Solder pin surface: Sn
- Dimensions: Length 14.00 mm, Width 19.00 mm, Height 10.9 mm
- Pin spacing: 2.6 mm, Hole diameter: 1.4 mm
- Constructional height: 10.9 mm
- Environmental: UL listed, China RoHS compliant
- Connection method: Push-in spring, suitable for wave soldering
- Application: Industrial automation, control systems
- Approval: cULus Recognized
Buy the Buy Phoenix Contact PCB Terminal Block Part Number SPTAF1535LL Online
Purchase the Phoenix Contact PCB terminal block SPTAF 1/5-3,5-LL online to benefit from quick, tool-free push-in connections, space-efficient design, and reliable long-term contact stability. Featuring 5 positions, a 3.5 mm pitch, and supporting conductor cross sections from 0.2 mm² to 1 mm², this industrial-grade component is ideal for automation, control systems, and wiring applications where space and efficiency are critical. Order now to enhance your project with high-quality, tested connection solutions.
Order your Phoenix Contact Series SPTAF1535LL PCB terminal block today and ensure reliable, quick wiring with space-saving efficiency for your control panels.
Frequently Asked Questions
Where can I buy Phoenix Contact SPTAF1535LL?
You can click on the BUY or RFQ button to purchase SPTAF1535LL from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part SPTAF1535LL?
You can download the SPTAF1535LL datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of SPTAF1535LL?
Phoenix Contact
