Phoenix Contact TDPT259SC508 PCB Terminal Block
The PCB terminal block TDPT 2,5/ 9-SC-5,08 is a reliable connection component designed for wave soldering applications, supporting a nominal current of 24 A and a voltage of 400 V. It features a 5.08 mm pitch and 9 positions with a screw connection method using tension sleeves, suitable for both solid and flexible conductors. Its durable, tin-plated copper contacts ensure excellent electrical performance and corrosion resistance. The green housing and compact dimensions make it versatile for various electronic and industrial applications with easy installation and secure wiring.
Phoenix Contact TDPT259SC508 PCB Terminal Block Specifications:
- Nominal current: 24 A
- Nominal voltage: 400 V
- Pitch: 5.08 mm
- Number of positions: 9
- Connection method: Screw connection with tension sleeve
- Mounting: Wave soldering
- Pin layout: Linear double pinning
- Rated insulation voltage: 400 V
- Rated surge voltage: 4 kV
- Conductor cross section (solid): 0.2 mm2 ... 4 mm2
- Conductor cross section (flexible): 0.2 mm2 ... 2.5 mm2
- Conductor cross section (AWG/Kem): 24 ... 12
- Material contact: Cu alloy, tin-plated
- Housing color: Green
- Dimensions: Length 18 mm, Width 46.52 mm, Height 19 mm
- Pin spacing: 8.7 mm
- Hole diameter: 1.4 mm
- Standards: EN-VDE, UL 94 VO
- Rated surge voltage: 4 kV
- Temperature range: -55°C to +105°C
Buy the Buy Phoenix Contact PCB Terminal Block Part Number TDPT259SC508 Online
Purchase the Phoenix Contact PCB terminal block TDPT 2,5/ 9-SC-5,08 online today. This 9-position, screw connection terminal offers a reliable, compact design with a 5.08 mm pitch, supporting 24 A current and 400 V voltage. Its wave soldering mount, durable tin-plated copper contacts, and green housing make it ideal for industrial and electronic applications. Easy to install with secure wiring, this high-quality connector guarantees consistent electrical performance, corrosion resistance, and meets international standards.
Order your Phoenix Contact Series TDPT 2,5/ 9-SC-5,08 terminal block today and ensure reliable, secure connections for your electronic projects.
Frequently Asked Questions
Where can I buy Phoenix Contact TDPT259SC508?
You can click on the BUY or RFQ button to purchase TDPT259SC508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part TDPT259SC508?
You can download the TDPT259SC508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of TDPT259SC508?
Phoenix Contact
