Phoenix Contact TDPT259SP508 PCB Terminal Block
This PCB terminal block features a 9-position linear configuration with a pitch of 5.08 mm, rated for 32 A current and 400 V voltage. It utilizes push-in spring connection technology for quick, tool-free wiring, and is suitable for wave soldering mounting. The device's green housing and color-coded actuation lever ensure intuitive installation and maintenance. Designed with tin-plated Cu alloy contacts, it offers reliable long-term contact stability, meeting IEC standards for electrical and mechanical robustness, making it ideal for PCB wiring in industrial and automation applications.
Phoenix Contact TDPT259SP508 PCB Terminal Block Specifications:
- Range of articles: TDPT 2,5/.-SP
- Pitch: 5.08 mm
- Number of positions: 9
- Connection method: Push-in spring connection
- Mounting: Wave soldering
- Rated current: 32A
- Rated insulation voltage: 400 V
- Rated surge voltage: 4kV
- Conductor cross section (solid/flexible): 0.2 mm² to 4 mm²
- Conductor cross section with ferrule (without/with plastic sleeve): 0.2 mm² to 2.5 mm²
- Material contact: Cu alloy, tin-plated
- Housing color: Green (6021)
- Dimensions: Length 18mm, Width 46.52 mm, Height 19mm, Solder pin length 3.5mm, Pin size 0.8 x 0.8 mm
- Pin spacing: 8.7 mm
- Hole diameter for PCB: 1.4 mm
- Ambient temperature (assembly): -6°C to 105°C
- Material adherence: IEC 60999-1 test passed
- Standards: IEC 60947-7-4, IEC 60068-2-54
Buy the Buy Phoenix Contact PCB Terminal Block Part Number TDPT259SP508 Online
Order the Phoenix Contact PCB terminal block TDPT 2,5/ 9-SP-5,08 online today. Equipped with push-in spring connection technology, this 9-position terminal provides quick, tool-free wiring, ideal for PCB applications. Its robust design features tin-plated Cu alloy contacts and a green housing for easy identification. The wave soldering compatible construction ensures durability and stable contact over long-term operation, making it perfect for automation systems and industrial wiring tasks. Experience seamless installation and dependable electrical performance with this reliable terminal block.
Buy Phoenix Contact TDPT259SP508 now and experience reliable, quick PCB wiring with push-in connections and long-term stability in industrial environments.
Frequently Asked Questions
Where can I buy Phoenix Contact TDPT259SP508?
You can click on the BUY or RFQ button to purchase TDPT259SP508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part TDPT259SP508?
You can download the TDPT259SP508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of TDPT259SP508?
Phoenix Contact
