Pomona Electronics 18255 Banana Jack and Plug Set
The green banana plug test plug and test jack are designed for secure, reliable electrical testing applications. Compatible with standard banana jacks and wire sizes, these plugs feature tarnish-resistant nickel or gold plating for low contact resistance. They support high temperatures up to 302°F and current ratings of 15 amps. Made with durable materials like beryllium copper, brass, and ABS insulation, these test accessories are ideal for precise testing setups, ensuring consistent performance, easy assembly with set screws, and broad compatibility with panel and binding post banana jacks.
Pomona Electronics 18255 Banana Jack and Plug Set Specifications:
- Fits wires from 22 AWG to 18 AWG, diameter up to 0.12 inches (3mm)
- Compatible with banana jacks of 0.161 to 0.166 inches (4.0 to 4.2mm) diameter
- Materials: Beryllium Copper, Brass, ABS insulation
- Plating: Nickel or gold for low contact resistance
- Temperature Rating: Up to 302°F (150°C) for Model 4899
- Voltage Rating: 5000 Vrms max in controlled environments, CE compliant at voltages below 33 Vrms/70 Vdc
- Current Rating: 15 Amps
- Set screw: Steel, zinc plated, for easy assembly
- Dimensions: approx. 7 inches in length, 0.161 to 0.166 inches (4.0–4.2mm) diameter openings
- Color options include black, brown, red, orange, yellow, green, blue, violet, gray, white
Buy the Buy Pomona Electronic Banana Jacks Part Number 18255 Online
Order Pomona banana jacks and plugs online today for your testing needs. These high-quality, durable connectors support temperatures up to 302°F and provide low contact resistance with nickel or gold plating. Designed for easy installation, they fit standard banana jacks and wires from 22 to 18 AWG. Ideal for electrical testing, they ensure secure, reliable connections across various applications. Purchase now and enhance your testing setup with top-grade, corrosion-resistant components for consistent, safe electrical performance.
Buy Pomona Electronic banana plugs and test jacks now and experience unmatched reliability and high-temperature performance.
Frequently Asked Questions
Where can I buy Pomona Electronics 18255?
You can click on the BUY or RFQ button to purchase 18255 from an authorized Pomona Electronics distributor.
How do I troubleshoot issues or seek technical support for part 18255?
You can download the 18255 datasheet or visit the Pomona Electronics website for support.
Who is the manufacturer of 18255?
Pomona Electronics
