RENESAS DA1453100FXDBP Bluetooth Low Energy SoC
The DA14531, also known as TINY™, is the world's smallest Bluetooth 5.1 System-on-Chip designed for ultra-low power IoT devices. It features a 32-bit ARM Cortex-M0+ processor, 48KB RAM, integrated power management, and supports up to 3 Bluetooth LE connections. Its compact 2.0 x 1.7 mm WLCSP package makes it ideal for disposable and embedded applications like beacons, health monitors, and smart labels. The chip offers efficient RF performance with a sensitivity of -94 dBm and low power consumption, enabling long-lasting battery life in small form factors.
RENESAS DA1453100FXDBP Bluetooth Low Energy SoC Specifications:
- Processing Power: 16 MHz 32-bit ARM Cortex-M0+
- Memory: 48 kB RAM, 144 kB ROM, 32 kB OTP
- Radio Sensitivity: -94 dBm
- Transmit Power: -20 dBm to +2.5 dBm
- Power Supply: 1.1 to 3.3V
- Package Options: WLCSP 17 (1.7x2.0 mm), FCGQFN 24 (2.2x3.0 mm)
- Hibernation Mode: 240nA @ 25°C
- Supported Bluetooth: 5.1 core features, up to 3 connections
- Integrated Power Management: Buck/Boost DCDC, Linear Bypass
- RF: Programmable power output, -94 dBm sensitivity
- Interfaces: UARTs, SPI, I2C, ADC, RTC, PWM, quadrature decoder
- Security: AES-128 encryption, TRNG, secure reset circuitry
Buy the Buy Dialog Semiconductor DA14531 Part Number DA1453100FXDBP Online
Purchase the Dialog Semiconductor DA14531 Bluetooth Low Energy System-on-Chip today and enhance your IoT projects with its ultra-low power consumption, compact 2.0 x 1.7 mm package, and support for Bluetooth 5.1 core. Its integrated power management, flexible interfaces, and long battery life make it ideal for disposable sensors, health devices, beacons, and smart labels. With multiple development tools and sample code available, this chip ensures fast integration, cost efficiency, and reliable performance for a wide range of connected applications.
Get Dialog Semiconductor DA14531 today—optimized for low power IoT applications with compact size and robust Bluetooth 5.1 connectivity.
