RENESAS R5F21246SNFPV2 Microcontroller
The R5F21246SNFP is a 16 Kbyte flash memory microcontroller in a 52-pin PLQPO052JA-A package, suitable for embedded applications requiring up to 85°C operational ambient temperature. It features a 16-bit CPU core, 1 Kbyte internal RAM, and supports sophisticated instruction sets for high efficiency, making it ideal for industrial, consumer, and automation systems. Variants include high- and low-voltage versions, with factory programmed ROM options, robust performance at various supply voltages, and extensive peripheral interfaces including timers, serial communication, and A/D conversion capabilities.
RENESAS R5F21246SNFPV2 Microcontroller Specifications:
- Flash Memory Capacity: 16 Kbytes
- Package Type: PLQPO052JA-A (0.65 mm pin-pitch, 10 mm square body)
- ROM Size: 16 Kbytes
- RAM Capacity: 1 Kbyte
- Operating Ambient Temperature: -20°C to 85°C
- Operational Voltage Range: 2.2 V to 5.5 V
- Instruction Set: 89 fundamental instructions, execution time 50 ns at 20 MHz
- Performance: Up to 85°C operating temperature, single-chip mode
- Peripheral Features: Timers, UART, I2C, LIN, A/D converter
- Clock Frequency: Up to 20 MHz with internal high-speed oscillator
- Power Dissipation: Max 17 mA at 20 MHz
- Factory Programmed ROM: Options available, pre-shipped
- Application: Industrial control, consumer electronic, automation systems
Buy the Buy Renesas R5F21246SNFP Part Number R5F21246SNFP Online
Purchase the Renesas R5F21246SNFP microcontroller online today. It offers 16 KB flash memory, 1 KB RAM, and operates reliably in ambient temperatures up to 85°C. Ideal for automation, industrial control, and consumer electronics, this compact 52-pin MCU features high-performance instruction execution, multiple communication interfaces, timers, and a robust package design. Available with factory pre-programmed ROM options, it ensures fast deployment and efficient system development, making it a perfect choice for diverse embedded applications requiring high speed and reliability.
Get Renesas R5F21246SNFP today—built for high-speed performance, extensive peripheral support, and reliable operation in industrial and embedded systems.
Frequently Asked Questions
Where can I buy RENESAS R5F21246SNFPV2?
You can click on the BUY or RFQ button to purchase R5F21246SNFPV2 from an authorized RENESAS distributor.
How do I troubleshoot issues or seek technical support for part R5F21246SNFPV2?
You can download the R5F21246SNFPV2 datasheet or visit the RENESAS website for support.
Who is the manufacturer of R5F21246SNFPV2?
RENESAS
