ROHM SCS210AMC Silicon Carbide Schottky Diode
The SCS210AM is a high-performance silicon carbide Schottky barrier diode designed for fast switching and low loss applications. Featuring a 650V reverse voltage, 10A continuous forward current, and a low forward voltage drop of approximately 1.55V at 150°C, it offers reliable operation within a junction temperature of 175°C. Its compact TO-220FM package ensures easy integration into power supplies, inverters, and industrial circuits. The diode's reduced recovery time and high-speed switching capabilities make it ideal for high-efficiency power conversion and rugged industrial environments.
ROHM SCS210AMC Silicon Carbide Schottky Diode Specifications:
- Reverse Voltage: 650V
- Continuous Forward Current: 10A
- Surge Forward Current: 150A
- Repetitive Peak Forward Current: 26A
- Total Power Dissipation: 34.6W
- Junction Temperature: 175°C
- Storage Temperature Range: -55°C to +175°C
- Forward Voltage: 1.55V at 10A, Tj=150°C
- Reverse Current: 30-70pA at 600V, Tj=150-175°C
- Capacitance at 600V, 1MHz: 37pF
- Total Capacitance: 37pF
- Thermal Resistance (junction to case): 3.6°C/W
- Package Type: TO-220FM
Buy the ROHM Series SCS Silicon Carbide Diode: 650V 10A SCS210AM
Purchase the ROHM SCS210AM diode online today to benefit from its high-voltage capability, fast switching speed, and low forward voltage. Ideal for efficient power supply design, inverter circuits, and rugged industrial environments, this diode offers robust performance with a maximum reverse voltage of 650V and a continuous forward current of 10A. The compact TO-220FM package simplifies installation and ensures reliable thermal management. Order now and enhance your power conversion systems with this durable, high-performance Schottky diode.
Buy ROHM SCS210AM diode now and experience unmatched reliability and high-speed switching for power and industrial applications.
Frequently Asked Questions
Where can I buy ROHM SCS210AMC?
You can click on the BUY or RFQ button to purchase SCS210AMC from an authorized ROHM distributor.
How do I troubleshoot issues or seek technical support for part SCS210AMC?
You can download the SCS210AMC datasheet or visit the ROHM website for support.
Who is the manufacturer of SCS210AMC?
ROHM
