Raychem TE Connectivity 382S02325C0 Molded Boots
Rayaten molded boots with shielding are rugged, lightweight, and environmentally sealed components designed for aerospace, defense, and marine applications. They provide superior EMI attenuation of 70 dB up to 1 GHz, ensuring excellent shielding and reliable strain relief. Made from high-performance compounds, these heat-shrinkable molded parts are compatible with standard and low fire hazard options. They are suitable for sealed harness applications on military vehicles, missile systems, naval ships, and flight control systems, offering enhanced EMI performance and ease of installation in harsh environments.
Raychem TE Connectivity 382S02325C0 Molded Boots Specifications:
- Shielding Effectiveness: 70 dB attenuation up to 1 GHz
- Continuous Operating Temperature: -75°C to +150°C (System 25), -30°C to +105°C (System 100)
- Electrical Screening Performance: 75 dB at 3 kHz-30 MHz, >70 dB at 30 MHz-100 MHz, 65 dB at 3 kHz-1100 MHz
- Material: Heat-shrinkable with options for System 25 (standard) and System 100 (low fire hazard)
- Installation: Coated straight, 90°, and 45° molded parts, D-Subminiature connectors, transition molded parts
- Product Type: Molded boots with Rayaten shielding for sealed harness applications
- Application Environments: Aerospace, defense, marine, military ground vehicles, radar, missile launchers, flight control systems
Buy the Buy TE Connectivity Rayaten Molded Boots Part Number 382S02325C0 Online
Purchase TE Connectivity Rayaten molded boots online today and experience the highest level of EMI shielding, reliable strain relief, and environmental sealing. These rugged, lightweight components are ideal for aerospace, defense, and marine applications, offering ease of installation with standard and low fire hazard options. Designed for sealed harness systems, they provide up to 70 dB attenuation up to 1 GHz, ensuring your equipment operates reliably in harsh environments. Order now for superior performance and end-to-end sealing solutions.
Buy TE Connectivity Rayaten molded boots now and enhance EMI shielding, durability, and environmental sealing for your aerospace and defense applications.
Frequently Asked Questions
Where can I buy Raychem TE Connectivity 382S02325C0?
You can click on the BUY or RFQ button to purchase 382S02325C0 from an authorized Raychem TE Connectivity distributor.
How do I troubleshoot issues or seek technical support for part 382S02325C0?
You can download the 382S02325C0 datasheet or visit the Raychem TE Connectivity website for support.
Who is the manufacturer of 382S02325C0?
Raychem TE Connectivity
