Raychem TE Connectivity CES3 Cable Seal
The CES-3 is a heat-shrinkable cable entry seal made from flame-retardant polyolefin, designed to provide a watertight and fume-tight seal at the points where cables enter connection boxes, bulkheads, or other enclosures. This standard seal features a thin-wall construction comprising a three-part assembly: a rigid plastic nylon nut, an O-ring, and a heat-shrinkable molded section. It can be configured with a single opening for one cable or multiple openings with two, three, or four legs to accommodate several cables entering an enclosure or bulkhead. Factory-applied adhesive enhances sealing by bonding to wire and cable jackets. Suitable for sealing multi-cable entries in various environments, including wet, dry, and corrosive conditions, adhering to U.S. Coast Guard standards.
Raychem TE Connectivity CES3 Cable Seal Specifications:
- Material: Flame-retardant polyolefin
- Temperature rating: 55°C to 90°C
- Minimum shrink temperature: 121°C
- Adhesive: Hot melt adhesive RW-2019
- Folded length: 69.85 mm (2.75 inches) for standard sizes
- Number of legs: 1 to 4 configurations available
- Sealing method: Heat shrinking at 121°C-135°C
- Environmental resistance: Wet, dry, corrosive conditions
- Compliance: U.S. Coast Guard standards
- Application: Seals cable entry points, connection boxes, bulkheads in industrial environments
Buy the Tyco Series CES3 Cable Seal: CES3
Purchase the Tyco Series CES3 heat-shrinkable cable seal online today for reliable, watertight, and fume-tight sealing of multiple cables entering enclosures. Designed with factory-applied adhesive, it guarantees a secure bond to cable jackets. Suitable for various environments including wet, dry, and corrosive conditions, meeting U.S. Coast Guard standards. Easy to install by applying heat at 121°C-135°C, ensuring a snug fit for single or multiple cables with configurations of one, two, three, or four legs. Protect your connections with durable sealing solutions.
Order your Tyco Series CES3 cable entry seal today and ensure a secure, reliable, and watertight seal for your industrial cable connections.
Frequently Asked Questions
Where can I buy Raychem TE Connectivity CES3?
You can click on the BUY or RFQ button to purchase CES3 from an authorized Raychem TE Connectivity distributor.
How do I troubleshoot issues or seek technical support for part CES3?
You can download the CES3 datasheet or visit the Raychem TE Connectivity website for support.
Who is the manufacturer of CES3?
Raychem TE Connectivity
