Raychem TE Connectivity D1811222909 Coaxial Solder Sleeve
The D-181-1222-90/9 is a 3.7mm coaxial solder sleeve with heat-shrink insulation made of radiation-cross-linked polyvinylidene fluoride. It features a pre-installed lead and Sn63 solder, designed for terminating silver or tin-plated conductors and shields of coaxial cables rated for at least 125°C. The component includes meltable fluorocarbon rings, supports stranded 22 AWG wire, and offers immersion protection. With an operational temperature up to 150°C, it is suitable for industrial, telecommunications, and electronic applications demanding high-temperature, reliable cable terminations.
Raychem TE Connectivity D1811222909 Coaxial Solder Sleeve Specifications:
- Insulation Sleeve: Heat-shrinkable, radiation cross-linked polyvinylidene fluoride, transparent blue
- Solder Material: Sn63, per ANSI J-STD-006
- Flux: ROLI, per ANSI J-STD-004
- Meltable Rings: Fluorocarbon-based thermoplastic
- Conductor Lead: MIL-W-22759/32-GA-9, white
- Ground Lead: MIL-W-22759/32-GA-90, white with black stripe
- Wire Range: 0.25 to 0.7 (0.010 to 0.027 inches)
- Shield Diameter: 1.0 to 3.2 (0,04 to 0.125 inches)
- Jacket Diameter: 1.5 to 3.6 (0.060 to 0.140 inches)
- Temperature Rating: at least 125°C, operational up to 150°C
- Compatibility: Suitable for coaxial cables with stranded 22 AWG wire
- Application: Suitable for industrial electrical and communications wiring where high temperature and reliable shielding are required.
Buy the Buy TE Connectivity Coaxial Solder Sleeve Part Number D1811222909 Online
Purchase the TE Connectivity coaxial solder sleeve D1811222909 online today. Designed for high-temperature cable terminations, this product features heat-shrink insulation, a pre-installed lead, and Sn63 solder. It supports cable diameters from 1.5 to 3.6 mm, with a temperature rating of at least 125°C and operational capability up to 150°C. Ideal for industrial, telecommunications, and electronic applications, it ensures secure, durable connections with excellent insulation and corrosion resistance. Order now to ensure reliable, long-lasting cable terminations with professional-grade components.
Get TE Connectivity D1811222909 today—built for precision, reliable high-temperature cable termination, and long-lasting durability.
Frequently Asked Questions
Where can I buy Raychem TE Connectivity D1811222909?
You can click on the BUY or RFQ button to purchase D1811222909 from an authorized Raychem TE Connectivity distributor.
How do I troubleshoot issues or seek technical support for part D1811222909?
You can download the D1811222909 datasheet or visit the Raychem TE Connectivity website for support.
Who is the manufacturer of D1811222909?
Raychem TE Connectivity
