Red Lion Controls PAXLVD00 DC Volt Meter
The PAXLVD00 is a 253VAC PAX Lite DC voltmeter featuring a 3.5-digit, 0.56-inch (14.2mm) LED display with polarity indication. It is designed with a 1/8 DIN size (50mm x 97mm), offering built-in scaling options with selectable decimal point positions and auto zeroing circuits. The device includes over-range indication and a sealed front bezel with NEMA 4X/IP65 sealing, making it suitable for demanding sensing and instrumentation applications.
Red Lion Controls PAXLVD00 DC Volt Meter Specifications:
- Display: 3.5-digit, 0.56 inch high LED
- Polarity indication included
- Size: 1/8 DIN, 50mm x 97mm
- Maximum Voltage: 253VAC for DC measurement
- Sealed front bezel: NEMA 4X/IP65
- Built-in scaling with selectable decimal points
- Auto zeroing circuits
- Over-range indication by blanking least significant digits
- Power supply: 115/230 VAC switchable, 6 VA
- Input Impedance: Voltage: 1 MΩ, Current: 1000.1 KΩ
- Temperature Range: Operating 0°C to 60°C, Storage -40°C to 80°C
- Vibration: 5-150 Hz, 2g, 1.5 hours
- Ingress Protection: NEMA 4X/IP65
- Certifications: UL Recognized, CSA Listed, IEC 61010-1
Buy the Red Lion Series PAX Lite DC Voltmeters: PAXLVD00
Get the Red Lion PAXLVD00 DC voltmeter online today for accurate, reliable voltage readings in demanding industrial environments. Featuring a high-visibility LED display, built-in scaling, auto zeroing, and a sealed NEMA 4X/IP65 front, this device is perfect for sensing and instrumentation applications. Its compact 1/8 DIN size makes installation easy, while the switchable power supply ensures versatility across various setups. Trust Red Lion for quality measurement solutions that deliver precision and durability in challenging conditions.
Order your Red Lion Series PAXLVD00 today and ensure reliable DC voltage measurement for your industrial sensing projects.
Frequently Asked Questions
Where can I buy Red Lion Controls PAXLVD00?
You can click on the BUY or RFQ button to purchase PAXLVD00 from an authorized Red Lion Controls distributor.
How do I troubleshoot issues or seek technical support for part PAXLVD00?
You can download the PAXLVD00 datasheet or visit the Red Lion Controls website for support.
Who is the manufacturer of PAXLVD00?
Red Lion Controls
