Red Lion Controls PAXT0000 Datasheet & Stock

The PAXT0000 is a 5-digit AC powered PAX® Temperature Meter with red sunlight readable display. The PAX® analogue panel meter offers many features and performance capabilities to suit a wide range of industrial applications. The option cards allow the opportunity to configure the meter for present applications, while providing easy upgrades for future needs. The meter employs a bright 0.56-inch LED display. The unit is available with a red sunlight readable or a standard green LED. The intensity of display can be adjusted from dark room applications up to sunlight readable, making it ideal for viewing in bright light applications. It provides a MAX and MIN reading memory with programmable capture time. The capture time is used to prevent detection of false max or min readings which may occur during start-up or unusual process events. This can be used to provide readout of totalized flow, calculate service intervals of motors or pumps.




Variable intensity display

Programmable function keys/user inputs

Four set-point alarm outputs (with option card)

Communication and bus capabilities (with option card)

Retransmitted analogue output (with option card)

Crimson programming software

Thermocouple and RTD inputs

Time-temperature integrator

Conforms to ITS-90 standards

IP65/NEMA-4X Protection rating





Applications


Industrial,

Metering





Warnings
Do not use this unit to directly command motors, valves or other actuators not equipped with safeguards. To do so can be potentially harmful to persons/equipment in the event of fault to the unit.
