SAMTEC IPL111601LDK Discrete Wire Header
The IPL1 series provides versatile discrete wire headers designed for surface mount, right-angle, elevated, and vertical through-hole applications. Crafted with natural LCP insulators and phosphor bronze terminals, these headers feature Sn or Au over Ni plating for excellent conductivity and corrosion resistance. Operating across -55°C to +125°C, they support voltages up to 675 VAC/954 VDC. Suitable for secure wire-to-header connections, they include options with guide post holes, polarization, and various sizes, ensuring flexibility for diverse electronic and industrial assembly needs.
SAMTEC IPL111601LDK Discrete Wire Header Specifications:
- Insulator Material: Natural LCP
- Terminal Material: Phosphor Bronze
- Plating: Sn or Au over 50 µ" Ni
- Operating Temperature: -55°C to +125°C
- Voltage Rating: 675 VAC/954 VDC
- RoHS Compliance: Yes
- Lead-Free Solderability: Yes
- Lead Style: S & -D (02 Lead Style)
- SMT Lead Coplanarity: Max 0.10 mm (0.004") for 02-05 sizes
- SMT Lead Coplanarity: Max 0.15 mm (0.006") for 11-25 sizes
- Compatible with: Discrete wire cables, MMSD, MMSS, MMSDT, MMSST
- Application: Surface mount, right-angle, elevated, through-hole, polarization options, guide post holes, with or without plug
- Material to support up to 675 VAC and operating temperatures up to +125°C
Buy the Samtec Series IPL1 Discrete Wire Header: IPL111601LDK
Purchase the Samtec IPL1 series discrete wire header online today and enjoy high-quality, versatile interconnect solutions suitable for a range of electronic and industrial applications. Featuring natural LCP insulators and phosphor bronze terminals with tin or gold plating, these headers support voltages up to 675 VAC/954 VDC and temperatures from -55°C to +125°C. Designed for surface mount, right-angle, elevated, and vertical through-hole mounting, they ensure secure and reliable wire connections with options for polarization, guide post holes, and various sizes for flexible assembly needs.
Buy Samtec IPL1 series IPL111601LDK now and experience unmatched reliability and performance in wire-to-board connections.
Frequently Asked Questions
Where can I buy SAMTEC IPL111601LDK?
You can click on the BUY or RFQ button to purchase IPL111601LDK from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part IPL111601LDK?
You can download the IPL111601LDK datasheet or visit the SAMTEC website for support.
Who is the manufacturer of IPL111601LDK?
SAMTEC
