Schneider Electric XB6DA65B Industrial Pushbutton Switch
This is a blue rectangular flush pushbutton with spring return, designed for industrial control applications. Featuring 1 NO and 1 NC contacts with slow-break operation, it supports both momentary and maintained functions. The device has a 16 mm mounting diameter, IP65 protection, and a stainless steel spring mechanism rated for 2 million cycles. Easy to install with faston connectors and certified for various safety standards, it ensures durability and reliable performance in demanding environments.
Schneider Electric XB6DA65B Industrial Pushbutton Switch Specifications:
- Shape of signaling unit: Rectangular
- Mounting diameter: 16 mm
- Overall width: 18 mm
- Overall height: 18 mm
- Overall depth: 57 mm
- Bezel material: Plastic
- Contacts: 1 NO + 1 NC, slow-break operation
- Connections: Faston connectors, 2.8 x 0.5 mm
- Operating position: Any position
- Operating travel: 1 mm NO, 2 mm NC, total 3.5 mm
- Operating force: 3.5 N NO, 4.5 N NC
- Mechanical durability: 2,000,000 cycles
- Contacts material: Silver alloy
- Rated insulation voltage: 250 V
- Rated impulse withstand voltage: 4 kV
- Rated operational current: 3 A at 120 V, AC-15
- Electrical durability: 1,000,000 cycles at AC-15 230 V
- Protection class: IP65
- Standards: UL 508, IEC 60947-1
- Vibration resistance: ±3mm 2-500 Hz
- Shock resistance: 30 g for 18 ms
Buy the Schneider Electric Series XB6 Pushbutton: XB6DA65B
Order the Schneider Electric XB6DA65B pushbutton online now to ensure reliable control and durability in your automation setup. This high-quality industrial switch features a robust design with IP65 protection, rated for over 2 million cycles, and supports versatile applications with its 16 mm mounting diameter and faston connectors. Perfect for controls requiring visual indication and easy operation, it meets international standards including UL, IEC, and CSA certifications, providing peace of mind and long-lasting performance in demanding environments.
Get Schneider Electric XB6DA65B today—built for durability and reliable switching in industrial control systems.
Frequently Asked Questions
Where can I buy Schneider Electric XB6DA65B?
You can click on the BUY or RFQ button to purchase XB6DA65B from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part XB6DA65B?
You can download the XB6DA65B datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of XB6DA65B?
Schneider Electric
