Schneider Electric ZB4BW0B61 LED indicator light
The ZB4BWOB61 is a blue LED indicator light with a 24V AC/DC supply, designed for industrial control panels. It features an integral LED bulb with an IP66 protection rating, mechanical durability of 5,000,000 cycles, and a compact 30mm width. The device includes screw clamp terminals conforming to EN 60947-1, with a typical operating force of 2.3N and an operating travel of 2.6mm. Suitable for harsh environments, this indicator meets standards like IEC 60947-5-4 and UL 508, offering reliable signaling for electrical panels and automation systems.
Schneider Electric ZB4BW0B61 LED indicator light Specifications:
- Supply Voltage: 24 V AC/DC, 50/60 Hz
- Light source: Protected LED, Blue
- Dimensions: Width 30mm, Height 47mm, Overall depth varies
- Contacts: 1NO, Slow-break, Silver alloy (Ag/Ni)
- Electrical durability: 1,000,000 cycles at AC-15, 3 A, 120 V
- Mechanical durability: 5,000,000 cycles
- Protection class: IP66
- Screw terminal: 2x 1.5 mm² with cable end conforming to EN 60947-1
- Tightening torque: 0.8 to 1.2 N.m
- Operating force: 2.3 N
- Operating travel: 2.6mm (Electrical), 4.3mm (Total)
- Standards: IEC 60947-5-4, UL 508, CSA, JIS C 4520
- Vibration resistance: 5 gn, Shock resistance: 30-50 gn
- Certifications: UL listed, DNV, CSA, RINA, GL, Lloyd's Register, BV
- Service life: 100,000 hours at rated voltage and temperature
- Environment: -40°C to +70°C, Protection against electric shock Class I
Buy the Buy Harmony XB4 Indicator Light Part Number ZB4BWOB61 Online
Enhance your control panel with the Harmony XB4 LED indicator light, featuring a blue LED, 24V AC/DC supply, and robust IP66 protection. Designed for durability, it withstands over 5 million operating cycles and harsh environments. Easy to install with screw clamp terminals conforming to EN 60947-1, it offers reliable signaling in automation and industrial systems. Perfect for ensuring operational safety and visual indication in demanding electrical environments, this indicator light combines quality and efficiency, making it essential for industrial control and automation solutions.
Buy Harmony XB4 ZB4BWOB61 now and experience unmatched reliability and performance for industrial signaling applications.
