Schneider Electric ZB4FA133 Industrial Pushbutton
The flush-mounted white pushbutton head with a black START marking is designed for industrial control applications. It features a round, built-in-flush head with a spring return operator profile. Made with chromium-plated metal, it has a mounting diameter of 1.20 inches (30.5 mm), and measures 1.44 inches (36.6 mm) in width and height with a depth of 1.22 inches (31 mm). It boasts high durability with 10 million cycles, protection ratings up to IP69K, and conforms to IEC, UL, and CSA standards, suitable for harsh environments and automation systems.
Schneider Electric ZB4FA133 Industrial Pushbutton Specifications:
- Mounting diameter: 1.20 inches (30.5 mm)
- Overall width: 1.44 inches (36.6 mm)
- Overall height: 1.44 inches (36.6 mm)
- Overall depth: 1.22 inches (31 mm)
- Mechanical durability: 10,000,000 cycles
- IP rating: IP66, IP67, IP69, IP69K (IEC 60529)
- Protection classes: Type 13, 12, 4, 4X (UL 50E)
- IK degree of protection: IKO6 (IEC 50102)
- Operating temperature: -40°F to 158°F (-40°C to 70°C)
- Vibration resistance: 5 gn, IEC 60068-2-6
- Shock resistance: 30 gn, IEC 60068-2-27
- Material: Chromium plated metal
- Standards: EN/IEC 60947-5-1, UL 508, CSA
- Certifications: UL Listed, CSA, cUL, EAC
- Weight: 1 lb (0.45 kg)
- Package dimensions: 2.47 in x 2.05 in x 1.69 in
Buy the Schneider Series XB4 ZB4FA133: Pushbutton Switch
Order the Schneider Electric pushbutton ZB4FA133 online today to ensure high durability, IP69K protection, and reliable operation for demanding industrial controls. Designed with a white flush mount and a black START marking, this pushbutton features a robust chromium-plated metal bezel and a built-in-flush round head, making it ideal for harsh environments. It withstands 10 million mechanical cycles, conforms to IEC and UL standards, and offers IP66 to IP69K protection ratings. Easy to install and perfect for automation and control panels—buy now for long-lasting performance and superior reliability.
Get Schneider ZB4FA133 today—built for precision, durability, and reliable control in industrial environments.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FA133?
You can click on the BUY or RFQ button to purchase ZB4FA133 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FA133?
You can download the ZB4FA133 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FA133?
Schneider Electric
