Schneider Electric ZB4FG0 Selector Switch Head
The flush mounted selector switch head ZB4FGO features a round shape with a chromium-plated metal bezel, designed for industrial control panels. It offers 3-position stay-put operation with a black key switch operator profile and Ronis 455 keylock. The head is built-in-flush, measuring 1.20 inches (30.5 mm) in mounting diameter, with overall dimensions of 1.44 inches (36.6 mm) width and height, and a depth of 1.93 inches (49 mm). It withstands high-pressure washings, has mechanical durability of 1,000,000 cycles, and conforms to IP66, IP67, IP69 ratings, suitable for harsh environments. Certifications include UL, CSA, and CE, ensuring compliance with safety standards. Rated for operation from -40°F to 158°F, it supports various mounting configurations and withstands significant mechanical and electrical challenges, making it ideal for industrial automation and control applications.
Schneider Electric ZB4FG0 Selector Switch Head Specifications:
- Bezel Material: Chromium plated metal
- Mounting Diameter: 1.20 inches (30.5 mm)
- Overall Width: 1.44 inches (36.6 mm)
- Overall Height: 1.44 inches (36.6 mm)
- Overall Depth: 1.93 inches (49 mm)
- Shape of Signaling Unit: Round
- Operator Profile: Black key switch
- Operator Position: 3+/-45° positions
- Key Lock: Ronis 455
- Key Withdrawal: In any position
- Resistance to High-Pressure Washer: 7,000,000 Pa at 55°C, 0.1m distance
- Mechanical Durability: 1,000,000 cycles
- IP Degree of Protection: IP66, IP67, IP69K
- IK Degree of Protection: IKO6
- Ambient Temperature (Storage & Operation): -40°F to 158°F (-40°C to 70°C)
- Vibration Resistance: 5 gn, 10-500 Hz; IEC 60068-2-6
- Shock Resistance: 30 gn (18 ms), IEC 60068-2-27; 50 gn (11 ms), IEC 60068-2-27
- Certifications: UL Listed, CSA, CE
- Standard Compliance: EN/IEC 60947-5-1, UL 508, JIS C8201, CE, RoHS, REACH
- Environmental Rating: IP66/IP67/IP69K, IK06
- Package Weight: 0.45 kg (1 lb)
- Operating Temperature: -40°F to 158°F (-40°C to 70°C)
Buy the Schneider Electric ZB4FG0 – Reliable Selector Switch Head for Industrial Applications
Enhance your industrial control systems with this durable, high-quality selector switch head designed for harsh environments. Featuring a round shape, a chromium-plated metal bezel, and a robust internal mechanism, it offers 3-position stay-put operation ideal for process control and automation. Conforming to IP66, IP67, and IP69 standards, it resists dust, water, and high-pressure washings, ensuring long-lasting reliability. Easy to install with a mounting diameter of 1.20 inches, this switch head guarantees safety, durability, and consistent operation across demanding industrial applications. Purchase online today for fast delivery and trusted performance.
Order your Schneider Electric Series ZB4FG0 selector switch head today and give your control panels the dependable quality they deserve.
