Schneider Electric ZB4FG4 Selector Switch Head
The ZB4FG4 is a flush-mounted selector switch head with a round shape designed for industrial automation. It features a chromium-plated metal bezel, built-in flush head type, and a black key switch operator profile. Suitable for safety-critical applications, it withstands high-pressure washing up to 7,000,000 Pa at 55°C and offers durability of 1,000,000 cycles. Its compact design measures 1.44 inches in height and width, with a depth of 1.93 inches. Certified IP66/IP67/IP69K and IK06, it operates well within -40°F to 158°F environments, making it ideal for harsh environments. It adheres to IEC and UL standards, ensuring high safety and reliability.
Schneider Electric ZB4FG4 Selector Switch Head Specifications:
- Bezel material: Chromium plated metal
- Mounting diameter: 1.20 in (30.5 mm)
- Head type: Built-in-flush
- Shape: Round
- Operator profile: Black key switch
- Type of operator: Stay put
- Operator position: 2 positions at 90°
- Key withdrawal position: In any position
- Overall width and height: 1.44 in (36.6 mm)
- Overall depth: 1.93 in (49 mm)
- Net weight: 0.29 lb (0.133 kg)
- Resistance to high pressure washer: 7,000,000 Pa at 55°C
- Mechanical durability: 1,000,000 cycles
- IP protection: IP66/IP67/IP69K
- IK protection: IK06
- Operating temperature: -40°F to 158°F (-40°C to 70°C)
- Vibration resistance: 5 gn at 10-500 Hz
- Shock resistance: 30 gn (18 ms duration)
- Certifications: UL Listed, CSA, CCC, EAC
- Standards compliance: IEC 60947-5-1, IEC 60947-5-4, UL 508, IEC 60068-2-6, IEC 60068-2-27
- Package weight: 1 lb (0.45 kg)
Buy the Buy Schneider Electric ZB4FG4 Part Number ZB4FG4 Online
Order the Schneider Electric ZB4FG4 selector switch head today online to ensure quick delivery and reliable operation in demanding industrial settings. This high-quality, built-in flush type round switch features a metal bezel and a durable black key operator profile, withstanding harsh environments including high-pressure washing and extreme temperatures. Its IP66/IP67/IP69K protection ratings, exceptional mechanical durability of 1 million cycles, and compliance with IEC, UL, and CSA standards guarantee safety and longevity. Ideal for automation control, machinery, and safety applications, this switch guarantees performance and peace of mind.
Buy Schneider Electric ZB4FG4 now and experience unmatched reliability and durability for harsh industrial environments.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FG4?
You can click on the BUY or RFQ button to purchase ZB4FG4 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FG4?
You can download the ZB4FG4 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FG4?
Schneider Electric
