Schneider Electric ZB4FK1233 Illuminated Selector Switch
The ZB4FK1233 is a flush-mounted green illuminated selector switch head designed for industrial control panels. It features a built-in-flush head with a 2-position stay-put operator profile, suitable for signaling and control applications. Crafted from chromium-plated metal, it offers high durability with a mechanical life of 1,000,000 cycles and resistance to high pressure washing up to 7,000,000 Pa. The unit complies with multiple standards including IP66/IP67/IP69/IP69K and IEC 60947-5-1, making it ideal for harsh environments. Its compact design measures 1.44 inches in width and height with an overall depth of 1.85 inches, and it supports various electrical configurations with integrated LEDs.
Schneider Electric ZB4FK1233 Illuminated Selector Switch Specifications:
- Material: Chromium plated metal
- Head type: Built-in-flush
- Operator profile: Stay put
- Operator position: 2 positions 90°
- Mounting diameter: 1.20 in (30.5 mm)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.85 in (47 mm)
- Net weight: 0.17 Ib (0.078 kg)
- Resistance to high pressure washer: 7,000,000 Pa at 55°C
- Mechanical durability: 1,000,000 cycles
- IP protection: IP66/IP67/IP69/IP69K conforming to IEC 60529
- Vibration resistance: 5 gn 10-500 Hz
- Shock resistance: 30 gn for 18 ms, 50 gn for 11 ms
- Temperature range: -40°F to +158°F (-40°C to +70°C)
- Standards: UL, CSA, IEC 60947-5-1, JIS C8201-5-1
- Certifications: UL Listed, CSA, CCC, EAC
- Environmental resistance: Vibration, shock, high pressure washing
- Package weight: 1 lb (0.45 kg)
- Package dimensions: 2.47 x 2.09 x 1.77 inches
Buy the Schneider Series XB4 ZB4FK1233: Flush-Mounted Green Illum Selector Switch
Purchase the Schneider Series XB4 ZB4FK1233 online today and experience fast delivery of a high-quality, durable green illuminated selector switch designed for demanding industrial applications. Its built-in-flush head and 2-position stay-put operator profile ensure reliable operation in harsh environments. The unit meets IP66/IP67/IP69 standards, resisting high-pressure washing and vibration, making it ideal for control panels, signaling, and industrial equipment. Secure your order now and improve your control system’s dependability with this robust and versatile switch.
Order your Schneider Series XB4 ZB4FK1233 today and enhance your control panels with reliable, durable signaling solutions designed for harsh environments.
