Schneider Electric ZB4FV063 Pilot Light Head
The ZB4FV063 is a flush-mounted blue pilot light head compatible with integral LED systems, designed for industrial control panels. It features a round shape, with a 1.20-inch mounting diameter and overall dimensions of 1.44 inches in width, height, and 4.22 inches in depth. Made from chromium-plated metal, it offers IP66, IP67, and IP69Ingress protection, and withstands high-pressure washing up to 7,000,000 Pa. Suitable for harsh environments, it operates within -40°F to 158°F, conforming to IEC and UL standards, and is certified UL, CSA, and CE compliant.
Schneider Electric ZB4FV063 Pilot Light Head Specifications:
- Shape: Round
- Mounting Diameter: 1.20 in (30.5 mm)
- Overall Width: 1.44 in (36.6 mm)
- Overall Height: 1.44 in (36.6 mm)
- Overall Depth: 4.22 in (31 mm)
- Colour: Blue
- Bezel Material: Chromium plated metal
- Ingress Protection: IP66, IP67, IP69, IP69K, Type 13 UL 50E, Type 12 UL 50E, Type 4 UL 50E, Type 4X UL 50E
- Resistance to High Pressure Washer: 7,000,000 Pa at 55°C
- Operating Temperature Range: -40°F to 158°F (-40°C to 70°C)
- Vibration Resistance: 5 gn (10...500 Hz)
- Shock Resistance: 30 gn (18 ms), 50 gn (11 ms)
- Certifications: UL Listed, CSA, CE, EAC
- Standards: IEC 60947-5-4, IEC 60947-5-1, UL 508, JIS C8201-5-1
- Weight: 0.13 lb (0.058 kg)
- Packaging: 1 unit per package, with options for bulk packs up to 40 units
Buy the Buy Schneider Electric Pilot Light Head Part Number ZB4FV063 Online
Order the Schneider Electric Pilot Light Head ZB4FV063 online today. Designed for harsh environments, it features a blue LED lens, durable chromium-plated metal bezel, and is rated IP69 for water and dust resistance. Easy to install in control panels, it provides reliable visual signaling with high-pressure washer resistance. With certifications like UL, CSA, and CE, it ensures safety and compliance for industrial applications. Enhance your control system with this high-quality, long-lasting pilot light head available for quick online purchase.
Get Schneider Electric ZB4FV063 today—built for industrial control panels with rugged durability and premium protection.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FV063?
You can click on the BUY or RFQ button to purchase ZB4FV063 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FV063?
You can download the ZB4FV063 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FV063?
Schneider Electric
