Schneider Electric ZB4FW943 Illuminated Pushbutton
The flush-mounted red illuminated pushbutton head for integral LED illumination features a round shape with an 1.20-inch mounting diameter. Made from chromium-plated metal, it has an IP66/IP67/IP69 protection rating, ensuring robustness in harsh environments. The device supports high mechanical durability of 10 million cycles and resistance to high-pressure washing at 55°C, making it ideal for industrial automation systems. It complies with IEC standards and certifications including UL, CSA, and CE, and is designed for reliable, long-lasting operation with a protective illuminated ring and various electrical configurations for versatile applications.
Schneider Electric ZB4FW943 Illuminated Pushbutton Specifications:
- Mounting diameter: 1.20 in (30.5 mm)
- Bezel material: Chromium plated metal
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.22 in (31 mm)
- Net weight: 0.13 lb (0.06 kg)
- Resistance to high-pressure washer: 7,000,000 Pa at 55°C
- Mechanical durability: 10,000,000 cycles
- Ambient temperature for operation: -40°C to +70°C
- IP ratings: IP66, IP67, IP69, IP69K
- Standards: IEC 60947-5-1, IEC 60947-5-4, UL 508, CSA, CE
- Vibration resistance: 5 gn, 10-500 Hz
- Shock resistance: 30 gn for 18ms
- Certification: UL Listed, CSA, CCC, EAC
- Package weight: 1 lb (0.45 kg)
- Warranty: 18 months
Buy the Schneider Series Harmony XB4 Red Pushbutton: ZB4FW943
Purchase the Schneider ZB4FW943 illuminated pushbutton online to ensure robust industrial control in harsh environments. Featuring IP66/IP67/IP69 ratings, this round, chromium-plated metal head supports up to 10 million cycles, resisting high-pressure washing at 55°C. Its integral LED illumination with a protective ring enhances visibility. Ideal for automation and control panel applications, it complies with international standards including UL, CSA, and CE, ensuring safety and longevity. Order now for dependable operation with an 18-month warranty, suitable for demanding industrial settings.
Get Schneider ZB4FW943 today—built for industrial durability and reliable pushbutton control with illuminated LED features.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FW943?
You can click on the BUY or RFQ button to purchase ZB4FW943 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FW943?
You can download the ZB4FW943 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FW943?
Schneider Electric
