SCHRACK - TE CONNECTIVITY SSRMP240D10 Solid State Relay
The SSRMP Series mini puck solid state relay offers reliable switching for AC loads with high isolation and quick connect terminals. It features a 10A rms rated version compatible with 240 VAC line voltage, though variants up to 25A are available. Utilized in automation, industrial control, and power management, the relay has a UL-rated plastic case, LED indicator for status, and a form A (SPST-NO) configuration. Its compact design ensures easy panel mounting and excellent thermal handling, making it suitable for continuous duty applications requiring high reliability and fast switching performance.
SCHRACK - TE CONNECTIVITY SSRMP240D10 Solid State Relay Specifications:
- Control Voltage Range: 4-32 VDC
- Maximum Input Current: 1-20 mA
- Line Voltage: 240 VAC or 480 VAC
- Load Voltage Range: 78-280 V
- Load Current: 10A, 16A, 25A RMS
- Peak Surge Current: 100A, 160A, 208A
- Isolation Voltage: 4000V rms
- On-State Voltage Drop: 1.6V
- Leakage Current: 5mA at rated voltage
- Operating Temperature Range: -30°C to +80°C
- Case Material: UL-rated plastic, 94V-1
- Mounting: Panel mountable with quick connect terminals
- Thermal Management: Mount to heatsink maintaining 85°C base temperature
- Dimensions and mounting details available in outline diagram
Buy the Potter & Brumfield Series SSRMP: SSRMP240D10
Purchase the Potter & Brumfield SSRMP240D10 solid state relay online today for dependable operation in industrial automation, power control, and high-current switching. This compact, panel-mountable relay features a 10A RMS load capacity, UL-rated case, LED indicator, and quick connect terminals, ensuring quick installation and long-lasting durability. Designed for continuous duty, it provides high isolation and fast switching suitable for demanding environments. Secure your automation projects today with this reliable relay, ready for immediate delivery from authorized distributors.
Get Potter & Brumfield SSRMP240D10 today—built for reliable industrial control and high switching capacity.
Frequently Asked Questions
Where can I buy SCHRACK - TE CONNECTIVITY SSRMP240D10?
You can click on the BUY or RFQ button to purchase SSRMP240D10 from an authorized SCHRACK - TE CONNECTIVITY distributor.
How do I troubleshoot issues or seek technical support for part SSRMP240D10?
You can download the SSRMP240D10 datasheet or visit the SCHRACK - TE CONNECTIVITY website for support.
Who is the manufacturer of SSRMP240D10?
SCHRACK - TE CONNECTIVITY
