SCHROFF 34561228 Rugged Shielded Subrack
The SCHROFF EuropacPRO Rugged subrack (part number 34561228) is a robust solution for mounting electronic components in harsh environments. Designed for shock and vibration resistance up to 25g, it's ideal for applications in transportation, industrial automation, and telecommunications. The subrack features effective EMC shielding, ensuring reliable operation in electrically noisy environments. It's available as pre-configured kits or can be individually configured to meet specific customer needs, offering flexibility for various applications. The rugged design and comprehensive accessory options make it a versatile choice for demanding electronic systems.
SCHROFF 34561228 Rugged Shielded Subrack Specifications:
- Standards Approvals: IEC 60297-3-100, -101, - 102, -103, -104, -105, IEEE 1101.1, IEEE 1101.10/11, IEC 60529, IEC 61587-3, MIL 167, IEC 61587 DL 3, MIL 810 G, MIL 901
- Protection Type: IP 20
- Shock Vibration Resistance: Up to 25 g
- EMC Shielding: Typically 40 dB at 1 GHz, 30 dB at 2 GHz (VG 95373, part 15)
- Material: Aluminum, 3 mm
- Depth D: 295 mm
- Depth D1: 175 mm
- Board Depth: 160 mm
- Delivery Comprises: Side panel, front handle, rear corner profile, front/rear horizontal rails, threaded inserts, perforated strip, insulation strip, EMC cover plate, EMC rear panel, EMC gasketing material
- Kit Part Number (3U): 24567-149
- Kit Part Number (6U): 24567-449
- Guide Rails: 24560-351
- Screw Type: 24560-141
- ESD Clip: 24560-255
- Heavy PCB Guide Rail: 34562-881
- CCA Adaptor (VPX): 24566-004
- CCA Adaptor (CompactPCI): 24566-005
- Dual Fixing Materials Kit: 24566-109
Buy the 34561228 SCHROFF Rugged Shielded Subrack | myMectronic
Secure your SCHROFF 34561228 Rugged Shielded Subrack today and ensure reliable performance in your critical applications.
