SIEMENS 5SJ41017HG40 Mini Circuit Breaker
Siemens 5SJ4101-7HG40 Mini Circuit Breaker is UL 489-listed and designed for reliable branch circuit protection up to 240 VAC and 60 VDC. Suitable for residential and electronic applications, it features a C-curve trip characteristic for general device protection, with a magnetic trip point of 5 to 10 times the rated current and a thermal trip point of 1.13 to 1.45 times the protector rating. It supports 1 Ampere current, with a high interrupting capacity of 14kA, and is easy to install on standard DIN rails for versatile wiring options.
SIEMENS 5SJ41017HG40 Mini Circuit Breaker Specifications:
- Standards: UL 489, CSA C22.2 No. 5-02
- Poles: Single pole
- Rated Current: 1 Ampere
- Voltage Range: 240 VAC maximum, 60 VDC maximum
- Interrupting Rating: 14 kA
- Trip Characteristics: C (General device protection)
- Magnetic Trip Point: 5 to 10 times rated current
- Thermal Trip Point: 1.13 to 1.45 protector rating
- Operating Voltage: Minimum 24 VAC/DC, Maximum 240 VAC / 60 VDC
- Device Depth: 70 mm
- Conductor cross-section: AWG 14 to 4 (Cu only)
- Mounting: Standard DIN rail (35 mm)
Buy the Siemens Series 5SJ Control Circuit Protection: 5SJ41017HG40
Order the Siemens 5SJ4101-7HG40 mini circuit breaker online today for dependable control circuit protection up to 240 volts. Designed for residential and electronic applications, it features a C-curve trip characteristic ensuring safe operation against overloads and short circuits. With a high interrupting capacity of 14kA and easy DIN rail mounting, it's perfect for wired control panels and electrical distribution systems. Purchase online and enhance your electrical safety with Siemens quality and efficiency.
Buy Siemens 5SJ4101-7HG40 mini circuit breaker now and experience unmatched reliability and performance in branch circuit protection.
