STMICROELECTRONICS 1N5822RL Low Drop Schottky Rectifier
The STMICROELECTRONICS 1N5822RL is a low-drop Schottky rectifier specifically engineered for demanding applications like switch-mode power supplies and high-frequency DC-DC converters. Its key features include very small conduction losses, negligible switching losses, and extremely fast switching capabilities, contributing to improved efficiency and performance. The device's avalanche capability is also specified, enhancing its robustness. Packaged in the DO-201AD, it is a versatile solution for free wheeling, polarity protection, and small battery chargers, making it a valuable component in a wide range of industrial and consumer electronics designs.
STMICROELECTRONICS 1N5822RL Low Drop Schottky Rectifier Specifications:
- IF(AV): 3 A
- V RRM: 40 V
- T j: 150 °C
- VF (max): 0.475 V
- VRRM: 20 - 40 V
- IF(RMS): 10 A
- IFSM: 80 A
- PARM: 1700 W
- Tstg: - 65 to + 150 °C
- dV/dt: 10000 V/µs
- Rth (j-a): 80 °C/W
- Rth (j-l): 25 °C/W
- IR (Tj = 25°C VR = VRRM): 2 mA
- IR (Tj = 100°C): 20 mA
- VF (Tj = 25°C IF = 3 A): 0.475 V
- VF (Tj = 25°C IF = 9.4 A): 0.85 V
