STMICROELECTRONICS AEKPOWL5964V1 Digitally Controlled DC-DC Converter
The AEK-POW-L5964V1 expansion board provides a dual-channel, digitally controlled DC-DC converter solution for automotive applications requiring multiple voltage levels, such as USB-PD or infotainment systems. It incorporates synchronous MOSFETs, input/output voltage monitors, and thermal protection. The board is compatible with the AutoDevKit initiative and includes a demo application and code generator for the SPC5-STUDIO tool environment. It's designed to be plugged onto additional boards via a connector compatible with SPC58EC-DISP or AEK-MCUC4MLIT1 evaluation boards.
STMICROELECTRONICS AEKPOWL5964V1 Digitally Controlled DC-DC Converter Specifications:
- Output Current: Up to 3 A per channel
- Input Voltage Range: 6 to 14 V
- Fixed Output Voltages: 3.3 - 5 - 9 V
- Programmable Output Voltages: 3.3 - 11 V (20 mV steps)
- Board Size: 84.7 mm x 81.3 mm
- Maximum Component Height: 10 mm
- AutoDevKit Initiative: Included
- RoHS Compliant: Yes
- WEEE Compliant: Yes
- Applications: USB-PD 2.0 and 3.0 supplies, Car infotainment supply, In-car DC-DC modules
