STMICROELECTRONICS SG3524P PWM Controller Module
The SG3524 is a comprehensive pulse width modulation (PWM) regulator control circuit designed for power supplies, inverters, and switching regulators. It features dual outputs suitable for single-ended or push-pull applications, operating up to 300 kHz with minimal temperature variation. The chip includes an internal reference, error amplifier, programmable oscillator, and output transistors, offering reliable control for high-power applications. Its versatile features enable efficient regulation, making it ideal for transformerless voltage doubling, polarity conversion, and transformer-coupled DC-DC converters.
STMICROELECTRONICS SG3524P PWM Controller Module Specifications:
- Supply Voltage: 8 to 40V
- Reference Output Voltage: 46 to 54V, typical 50V
- Maximum Frequency: 300kHz
- Error Amplifier Gain: 60-80dB
- Output Voltage: 0.5 to 3.8V
- Collector Voltage: 40V
- Collector Current: 100mA
- Power Dissipation at Tamp: 1000mW
- Thermal Resistance Junction-Ambient: Max 80°C/W
- Timing Resistor Rr: 1.8KΩ to 100KΩ
- Timing Capacitor Cr: 0.001uF to 0.1uF
- Temperature Range: -65°C to 150°C
- Shutdown Current: 8-10mA
- Error Amp Offset Voltage: 2-10mV
- Voltage Stability: 1% across Vin 8-40V
- Output Current: Max 100mA
Buy the STMicroelectronics Series SG3524 PWM Power Control Circuit: SG3524P
Discover the powerful SG3524 pulse width modulation control circuit, ideal for power supplies, inverters, and switch-mode power systems. With dual uncommitted outputs, operation up to 300kHz, and low standby current of 8mA, it provides precise regulation for high-power projects. Incorporating internal reference, error amplifier, programmable oscillator, and fault protection circuitry, it ensures reliable performance in transformerless and transformer-coupled applications. Elevate your power control designs—order the SG3524P online today for exceptional efficiency and dependability.
Order your STMicroelectronics Series SG3524P PWM power control circuit today and enhance your high-power switching regulator projects with reliable, efficient control.
