STMICROELECTRONICS T435T600FP Power Triac
The T435T-600FP is a Snubberless™ Triac designed for general purpose AC switching applications, including motor speed controllers, lighting dimmers, and electrovalves. Its 4 A rms current rating and UL certified insulation at 2.0 kV rms make it ideal for power tools and kitchen equipment. The package is RoHS compliant, and the device offers high static and dynamic commutation, making it reliable for various industrial and consumer electronics. It features enhanced insulation, snubberless design, and is suitable for demanding power switching tasks, ensuring safety and durability in multiple applications.
STMICROELECTRONICS T435T600FP Power Triac Specifications:
- Maximum RMS On-state current: 4 A
- Peak non-repetitive surge current: 32 A
- Peak off-state voltage: 600 V
- Gate trigger voltage: 0.9 V (max)
- Gate trigger current: 35 mA (max)
- Threshold voltage: 1.6 V (max)
- Thermal resistance junction to case: 43 °C/W
- Junction to ambient: 60 °C/W
- Storage temperature range: -40 to +150°C
- Operating junction temperature: -40 to +125°C
- Insulation rms voltage: 2.0 kV
- Package: TO-220FPAB, RoHS & ECOPACK compliant
- Lead-free epoxy, environmental grade
- Dimensions: A=44mm, B=2.5-2.7mm, D=2.5-2.75mm, E=0.45-0.70mm, F=0.75-1mm
Buy the Buy STMicroelectronics T435T-600FP Power Triac Part Number T435T-600FP Online
Order the STMicroelectronics T435T-600FP Power Triac online today and benefit from fast shipping, authentic quality, and competitive pricing. This high-performance device features a 4 A rms on-state current, UL certified insulation at 2.0 kV rms, and RoHS compliance, making it suitable for a wide range of AC switching applications such as motor controllers, light dimmers, and electrovalves. Its snubberless design enhances reliability, enabling efficient power switching in demanding environments. Purchase now to improve the safety, durability, and performance of your electrical systems.
Buy STMicroelectronics T435T-600FP Triac now and experience unmatched reliability and performance for your AC switching needs. This robust component ensures safe and efficient power control in industrial, commercial, and consumer electronics. The device’s high surge current capacity and UL-certified insulation at 2.0 kV rms make it ideal for motor controllers, lighting dimmers, and kitchen appliances. Secure yours today online and enhance your project’s durability and safety with this high-quality Triac.
Frequently Asked Questions
Where can I buy STMICROELECTRONICS T435T600FP?
You can click on the BUY or RFQ button to purchase T435T600FP from an authorized STMICROELECTRONICS distributor.
How do I troubleshoot issues or seek technical support for part T435T600FP?
You can download the T435T600FP datasheet or visit the STMICROELECTRONICS website for support.
Who is the manufacturer of T435T600FP?
STMICROELECTRONICS
