STMICROELECTRONICS T635T8T Triac industrial switching component
The T635T-8T is a Snubberless™ medium current Triac in a TO-220AB package, designed for reliable AC switching, motor control, and light dimming applications. It features high static and dynamic commutation capabilities, operates in three quadrants, and can be used without a snubber circuit up to 800V. Suitable for general-purpose AC line load switching, it handles up to 6A rms, with an optional enhanced di/dt and dv/dt performance. Compliant with ECOPACK®2 standards, this device ensures durability in industrial and home appliance circuits.
STMICROELECTRONICS T635T8T Triac industrial switching component Specifications:
- Maximum on-state rms current: 6 A at Tj=135°C
- Peak surge current: Non-repetitive 45 A, Repetitive 47 A
- Off-state voltage: Up to 900 V
- Gate trigger current: Max. 60 mA at 12V
- Maximum junction temperature: -40°C to +150°C
- Storage temperature: -40°C to +150°C
- Lead temperature for soldering: 260°C for 10 seconds
- Package: TO-220AB with dimensions A=4.40-4.60 mm, b=0.61-0.88 mm, e=2.40-2.70 mm, L=13-14 mm
- Thermal resistance junction to case: 21 °C/W
- Thermal resistance junction to ambient: 60 °C/W
- Meets UL94 V-0 flammability rating, lead-free, and ECOPACK®2 standards
- Rated voltage: 800 V (VARM), 900 V (Vosm)
- Maximum gate power dissipation: 1 W
- Peak gate current: 4 A
Buy the STMicroelectronics T635T8T – Reliable Triac for Industrial Applications
Purchase the STMicroelectronics T635T8T Triac online today for high-reliability AC load switching, motor control, and lighting applications. Its robust design supports high static and dynamic commutation, operates up to 800V, and handles currents up to 6A rms. In a TO-220AB package, it is ECOPACK®2 compliant and designed for durability under demanding conditions. Whether for general-purpose AC switching, inrush current limiting, or overvoltage crowbar protection circuits, this versatile Triac ensures reliable performance. Order now to equip your projects with a proven, industrial-grade component that ensures optimal operational efficiency and durability.
Get STMicroelectronics T635T8T today—built for precision and long-lasting durability in industrial switching and motor control.
Frequently Asked Questions
Where can I buy STMICROELECTRONICS T635T8T?
You can click on the BUY or RFQ button to purchase T635T8T from an authorized STMICROELECTRONICS distributor.
How do I troubleshoot issues or seek technical support for part T635T8T?
You can download the T635T8T datasheet or visit the STMICROELECTRONICS website for support.
Who is the manufacturer of T635T8T?
STMICROELECTRONICS
