SUSUMU KRL1220ECR020FT1 High Current Metal Foil Resistor
The KRL series comprises metal foil low resistance chip resistors designed for high current sensing applications in automotive and industrial electronics. These resistors feature short side terminals for reliable contact and are available in sizes from 0510 to 50110, with power ratings ranging from 0.2W to 5W. They support resistance values from 5mΩ to 1000mΩ and are compliant with RoHS and AEC-Q200 standards. Their face-down constructions include options with either bottom-only or wrap-around terminals, suitable for power sources, converters, motors, and automation equipment operating up to 175°C.
SUSUMU KRL1220ECR020FT1 High Current Metal Foil Resistor Specifications:
- Size: 0510 to 50110
- Power Ratings: 0.2W to 5W
- Resistance Range: 5mΩ to 1000mΩ
- Operating Temperature: -55°C to 175°C
- Resistance Values: 5mΩ to 1000mΩ, available in E-6/E-12 series
- Terminal Types: Bottom only (D), Wrap around (E)
- Face-down construction
- Compliance: RoHS, AEC-Q200
- Available in high temperature (up to 175°C) and low EMF versions
- Physical Dimensions vary with size, typical terminal length approx. 2-3mm
- Suitable for automotive electronics, power supplies, converters, and motor control systems
Buy the Generic Resistors R1220 E – Reliable High Current Sensing for Industrial Applications
Purchase the high-quality metal foil low resistance chip resistors online now to ensure reliable performance in automotive, industrial, and power supply applications. These resistors feature face-down construction, multiple terminal options, and support high operating temperatures up to 175°C. They are RoHS and AEC-Q200 compliant, offering resistance values from 5mΩ to 1000mΩ, with power ratings from 0.2W to 5W. Designed for durability and precision, these resistors are ideal for power sources, converters, motors, and automation equipment, ensuring long-lasting reliability.
Get KRL series resistors today—built for precision, durability, and optimal performance in demanding industrial environments.
Frequently Asked Questions
Where can I buy SUSUMU KRL1220ECR020FT1?
You can click on the BUY or RFQ button to purchase KRL1220ECR020FT1 from an authorized SUSUMU distributor.
How do I troubleshoot issues or seek technical support for part KRL1220ECR020FT1?
You can download the KRL1220ECR020FT1 datasheet or visit the SUSUMU website for support.
Who is the manufacturer of KRL1220ECR020FT1?
SUSUMU
