SAMTEC BSH06001LDATR Industrial Socket
The BSH-060-01-L-D-RA-WT is a high-quality, insulated, surface-mount socket designed for industrial and electronic applications. Made with black LCP insulator material and phosphor bronze contacts, it features gold or tin plating over nickel, ensuring durability and excellent conductivity. Rated for 2 A per pin, it supports voltage up to 275 VAC, withstands 100 mating cycles, and operates within -55°C to +125°C. Its compact design includes various stack heights and optional edge mount capability, suitable for complex PCB configurations in automation and electronics industries.
SAMTEC BSH06001LDATR Industrial Socket Specifications:
- Contact Material: Phosphor Bronze
- Insulator Material: Black LCP
- Plating Options: Au or Sn over 50u" Ni
- Current Rating: 2 A per pin
- Voltage Rating: 275 VAC
- Operating Temperature Range: -55°C to +125°C
- Max Cycles: 100
- RoHS Compliant: Yes
- Lead-Free Solderable: Yes
- Stack Height Options: 8mm, 11mm, 16mm, 19mm, 22mm
- Processing Conditions: Affected by processing, consult machinery specs
- Edge Mount Capability: Yes
- Coplanarity: (0,10 mm) .004" max, (0,15 mm) .006" max
- Number of Positions per Row: 6, 9, 30, etc., with various options
- Dimensions and Layout: Customizable for applications requiring more than two connectors or 90 positions
- Certifications: Recognized for quality control, detailed at Samtec
Buy the Samtec BSH-060-01-L-D-RA-WT – Reliable Mechanical Connector for Industrial Applications
Discover the dependable performance of the Samtec BSH-060-01-L-D-RA-WT industrial socket, designed with high-quality materials and multiple stack height options. Ideal for demanding environments, it offers excellent durability, a current rating of 2 A per pin, and a voltage capacity of 275 VAC. Its RoHS compliance and lead-free construction make it suitable for modern manufacturing. Quickly purchase online and enhance your electronic or automation applications with reliable, high-performance connectors that meet your project specifications.
Order your Samtec BSH-060-01-L-D-RA-WT series socket today and ensure robust, high-quality connections for your PCB assemblies and automation projects.
Frequently Asked Questions
Where can I buy SAMTEC BSH06001LDATR?
You can click on the BUY or RFQ button to purchase BSH06001LDATR from an authorized SAMTEC distributor.
How do I troubleshoot issues or seek technical support for part BSH06001LDATR?
You can download the BSH06001LDATR datasheet or visit the SAMTEC website for support.
Who is the manufacturer of BSH06001LDATR?
SAMTEC
